AJA HDP3 3G-SDI to DVI-D and Audio Converter
Availability:
In stock 3-5 days
Original price
$879.00
-
Original price
$879.00
Original price
$879.00
$879.00
-
$879.00
Current price
$879.00
| /
The AJA HDP3 is a high-performance mini-converter that converts 3G-SDI, HD-SDI, and SD-SDI signals to HDMI, delivering high-quality video scaling and audio embedding. It’s ideal for monitoring workflows, offering frame sync, color correction, and compatibility with a wide range of professional displays.
- Converts 3G-SDI, HD-SDI, and SD-SDI to HDMI
- High-quality video scaling and deinterlacing
- Supports resolutions up to 1080p 60
- Frame synchronization for stable output
- Embedded audio from SDI to HDMI
- 2-channel analog audio output via RCA
- 10-bit color processing
- Color correction controls
- HDMI with Deep Color support
- USB port for configuration via AJA Mini-Config
- Locking power connector
- Universal power supply included
- Compact and durable design
- Video Input: 1x 3G/HD/SD-SDI (BNC connector)
- Video Output: 1x HDMI (Type A connector)
- Supported Input Formats:
- SD: 525i, 625i
- HD: 720p, 1080i
- 3G: 1080p at 50/59.94/60 fps
- Scaling: High-quality up/down/cross conversion
- Deinterlacing: Yes, advanced motion-adaptive
- Frame Synchronization: Yes
- Color Processing: 10-bit processing with color correction controls
- Audio Input: Embedded SDI audio (up to 16 channels)
- Audio Output:
- HDMI embedded audio (up to 8 channels)
- 2-channel analog audio (RCA)
- HDMI Output: Deep Color support
- Control Interface: USB for configuration via AJA Mini-Config
- Power: 5–20 VDC, locking power connector (universal power supply included)
- Dimensions: 5.8" x 3.1" x 1.0" (147 mm x 79 mm x 25 mm)
- Weight: 0.5 lb (0.23 kg)
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Storage Temperature: -40°C to 60°C (-40°F to 140°F)
- Operating Humidity: 10% to 90% non-condensing
- Operating Altitude: <3,000 meters (<10,000 feet)
