AJA HDR IMAGE ANALYZER 12G 1RU 12G-SDI Device for Real Time HDR Analysis with WaveformHistogramVectorscope Monitoring
MODEL: HDR IMAGE ANALYZER 12G
SKU: HDR-IMGYZR-12G
Real-time HDR image analysis with 12G-SDI support
Supports PQ, HLG, SDR, and other HDR formats
Waveform, histogram, and vectorscope monitoring
Extensive color gamut and dynamic range analysis
Supports 4K/UltraHD, 2K, and HD resolutions
Four simultaneous 12G-SDI inputs for multi-channel analysis
Audio level monitoring and analysis
False color display for quick visual assessment
Flexible layout options with multiple view configurations
Compatible with Rec.709, Rec.2020, and Rec.2100 standards
Remote control via integrated web interface
Ideal for broadcast, production, and post-production workflows
Real-time HDR image analysis with 12G-SDI support
Supports PQ, HLG, SDR, and other HDR formats
Waveform, histogram, and vectorscope monitoring
Extensive color gamut and dynamic range analysis
Supports 4K/UltraHD, 2K, and HD resolutions
Four simultaneous 12G-SDI inputs for multi-channel analysis
Audio level monitoring and analysis
False color display for quick visual assessment
Flexible layout options with multiple view configurations
Compatible with Rec.709, Rec.2020, and Rec.2100 standards
Remote control via integrated web interface
Ideal for broadcast, production, and post-production workflows
Video Inputs:
4x 12G-SDI BNC (multi-channel support)
Supports single-link, dual-link, and quad-link connections
Video Outputs:
1x 12G-SDI BNC for monitoring
1x HDMI 2.0 for local display
Supported Formats:
PQ (Perceptual Quantizer)
HLG (Hybrid Log Gamma)
SDR (Standard Dynamic Range)
Rec.709, Rec.2020, Rec.2100
Resolution Support:
4K/UltraHD (up to 60p)
2K/HD (up to 60p)
Monitoring Tools:
Waveform, Histogram, Vectorscope
False Color Analysis
Nits Level Monitoring
Color Gamut Analysis
Audio Monitoring:
16-channel embedded SDI audio analysis
Control Interface:
Ethernet port for remote access and control via web interface
Power Supply:
Dual redundant power supply (100-240V AC, 50/60 Hz)
Dimensions (W x D x H):
1RU Rackmount (19" x 10" x 1.75")
Weight:
Approximately 8.5 lb (3.86 kg)
Operating Temperature:
32 to 104°F (0 to 40°C)
Storage Temperature:
-40 to 140°F (-40 to 60°C)
Operating Humidity:
10-90% non-condensing
