Thunderbolt 3 Connectivity – High-speed data transfer for real-time 4K workflows.

12G-SDI & HDMI 2.0 – Supports high-bandwidth video input and output.

4K/UltraHD & HDR Support – Ensures high-quality capture and playback.

High Frame Rate (HFR) Support – Up to 60 fps for smooth video processing.

Apple ProRes & Avid DNxHR Encoding – Optimized for professional workflows.

Low Latency Capture & Playback – Ideal for live production and post-production.

Portable & Rugged Design – Perfect for on-set and studio environments.

Multi-Format Support – Compatible with SD, HD, 2K, UltraHD, and 4K video formats.

Embedded Audio Support – 16-channel SDI and 8-channel HDMI embedded audio.

Compatible with Leading Software – Works with Adobe Premiere, Final Cut Pro, Avid Media Composer, and more.

Thunderbolt 3 Connectivity – High-speed data transfer for real-time 4K workflows.

12G-SDI & HDMI 2.0 – Supports high-bandwidth video input and output.

4K/UltraHD & HDR Support – Ensures high-quality capture and playback.

High Frame Rate (HFR) Support – Up to 60 fps for smooth video processing.

Apple ProRes & Avid DNxHR Encoding – Optimized for professional workflows.

Low Latency Capture & Playback – Ideal for live production and post-production.

Portable & Rugged Design – Perfect for on-set and studio environments.

Multi-Format Support – Compatible with SD, HD, 2K, UltraHD, and 4K video formats.

Embedded Audio Support – 16-channel SDI and 8-channel HDMI embedded audio.

Compatible with Leading Software – Works with Adobe Premiere, Final Cut Pro, Avid Media Composer, and more.

Video Formats Supported:

4K (4096 x 2160p): 23.98, 24, 25, 29.97, 30, 47.95, 48, 50, 59.94, 60 fps

UltraHD (3840 x 2160p): 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps

2K (2048 x 1080p): 23.98, 24, 25, 29.97, 30, 47.95, 48, 50, 59.94, 60 fps

2K (2048 x 1080PsF): 23.98, 24, 25 fps

HD (1080p): 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps

HD (1080PsF): 23.98, 24, 25, 29.97, 30 fps

HD (1080i): 50, 59.94, 60 fps

HD (720p): 50, 59.94, 60 fps

SD (625i): 50 fps

SD (525i): 59.94 fps

Video Inputs:

SDI:

12G-SDI (SMPTE-2082): 12-bit*, 10-bit, 8-bit

6G-SDI (SMPTE-2081): 10-bit, 8-bit

3G-SDI (SMPTE-259/292/296/424/425): 12-bit*, 10-bit, 8-bit

1.5G-SDI (SMPTE 292M): Single Link 4:2:2, 10-bit, 8-bit

1.5G-SDI (SMPTE 372M): Dual Link HD 4:4:4, 12-bit*, 10-bit, 8-bit

270 Mbps SDI (SMPTE 259M-C): YCbCr 4:2:2, 10-bit, 8-bit

HDMI v2.0:

30/36-bits/pixel, RGB or YUV, 6 Gbps per color component

Supports: 4K, UltraHD, 2K, HD, SD

High Frame Rate (HFR) support up to 60p (4:2:2), 10-bit, 8-bit

Video Outputs:

SDI:

12G-SDI (SMPTE-2082): 12-bit*, 10-bit, 8-bit

6G-SDI (SMPTE-2081): 10-bit, 8-bit

3G-SDI (SMPTE-259/292/296/424/425): 12-bit*, 10-bit, 8-bit

1.5G-SDI (SMPTE 292M): Single Link 4:2:2, 10-bit, 8-bit

1.5G-SDI (SMPTE 372M): Dual Link HD 4:4:4, 12-bit*, 10-bit, 8-bit

270 Mbps SDI (SMPTE 259M-C): YCbCr 4:2:2, 10-bit, 8-bit

HDMI v2.0:

30/36-bits/pixel, RGB or YUV, 6 Gbps per color component

Supports: 4K, UltraHD, 2K, HD, SD

High Frame Rate (HFR) support up to 60p (4:2:2), 10-bit, 8-bit

HDR10 Support – HDR Infoframe metadata, HDMI 2.0a/CTA-861.3

HLG Support – HDMI 2.0b/CTA-861-G

Audio Inputs:

Digital:

16-Channel, 24-bit and 16-bit SDI embedded audio, 48 kHz sample rate, synchronous

8-Channel, 24-bit and 16-bit HDMI embedded audio, 48 kHz sample rate, synchronous
