AJA FiDO-1T-LC 3G-SDI to single-mode LC fiber optic transmitter, compact mini-converter for long-distance HD video signal transmission.

AJA FIBERLC-1-TX-R0 1-Channel 3G-SDI Single Mode LC Fiber Transmitter SFP

by AJA
Availability:
In stock 3-5 days
$374.00 - $374.00
$374.00
$374.00 - $374.00
$374.00

MODEL: FIBERLC-1-TX

SKU:  FIBERLC-1-TX
  • Overview
  • Features
  • Specifications

The AJA FiDO-1T-LC is a compact 3G-SDI to LC fiber optic transmitter designed for long-distance transmission of HD video signals over single-mode fiber. It delivers reliable, low-latency performance ideal for professional video workflows.

  • Converts 3G-SDI to LC fiber
  • Supports HD and SD video formats
  • Compact, rugged design
  • Single-mode fiber transmission
  • LC optical connector
  • Real-time, low-latency conversion
  • Supports embedded SDI audio
  • Ideal for long-distance signal transport
  • Locking power connector
  • Plug-and-play operation
  • Video Input: 1x 3G-SDI BNC, SMPTE 259/292/424
  • Video Output: 1x LC optical fiber
  • Supported Formats: Up to 1080p 60 (3G-SDI)
  • Audio Support: Embedded SDI audio
  • Fiber Type: Single-mode
  • Wavelength: 1310 nm
  • Max Cable Length: Up to 10 km (single-mode fiber)
  • Power: +5-20V DC, 1.6W
  • Connector Type: LC
  • Dimensions: 5.8" x 1.0" x 0.8" (147mm x 25mm x 20mm)
  • Operating Temperature: 0°C to 40°C (32°F to 104°F)
