Lectrosonics - DSQD/AES3 4-Channel Digital Wireless Receiver with AES3 Outputs (470-608 MHz)
Original price
$8,701.00
-
Original price
$8,701.00
Original price
$8,701.00
$8,701.00
-
$8,701.00
Current price
$8,701.00
| /
The Lectrosonics DSQD/AES3 is a high-performance 4-channel digital wireless receiver designed for professional audio environments requiring uncompromising signal integrity, flexibility, and scalability. Ideal for studio, live sound, and broadcast applications, the DSQD/AES3 offers a hybrid of advanced digital reception with AES3 digital outputs, as well as analog and Dante interface capabilities. With ultra-low latency, wide tuning bandwidth, and exceptional RF performance, the DSQD/AES3 ensures rock-solid reliability in the most demanding RF conditions. The 1RU design streamlines installation while offering intuitive front-panel operation and network control for integrated workflows.
The Key Features of the Lectrosonics DSQD/AES3:
- 4-channel digital wireless receiver in 1RU chassis
- AES3 digital audio outputs with word clock sync
- Simultaneous analog and Dante audio outputs
- Wide tuning bandwidth across available frequency blocks
- Ultra-low latency digital signal processing
- Front-panel OLED screen for setup and monitoring
- High-density modulation for RF spectrum efficiency
- Ethernet port for remote control and firmware updates
- Backward compatibility with legacy Lectrosonics digital transmitters
- Redundant power supply inputs for mission-critical reliability
The Detailed Specifications for the Lectrosonics DSQD/AES3:
- Frequency Range: Dependent on block, wideband up to 88 MHz
- Channels: 4 independent receiver channels
- Outputs: AES3 digital, analog (balanced XLR), Dante (Ethernet)
- RF Sensitivity: -110 dBm for 20 dB SINAD
- Latency: 1.4 ms typical end-to-end
- Word Clock: 75 ohm BNC input for AES3 sync
- Display: Front-panel OLED with menu navigation
- Control Interface: Ethernet (RJ45), USB for local setup
- Power: 100-240V AC, dual redundant inputs (external supplies optional)
- Dimensions: 1RU (19" x 1.72" x 9.5")
- Weight: 6.5 lbs (approximate)
- Compatibility: Supports Lectrosonics digital transmitters including DBu, DHu, and DCHT
