The Blackmagic Design ATEM 2 M/E Advanced Panel is a professional control surface for live production switchers. It offers two Mix/Effect (M/E) rows, each with 20 input buttons, providing direct access to multiple video sources. Each row has its own system control LCD and customizable labels for buttons. High-quality buttons, knobs, fader bars, and a 3-axis joystick enable precise control over transitions, fades, and digital video effects (DVE).

Blackmagic Design ATEM 2 M/E Constellation HD

by Blackmagic Design
Availability:
In stock 3-5 days
$2,529.00 - $2,529.00
$2,529.00
$2,529.00 - $2,529.00
$2,529.00

SKU: SWATEMSCN2/1ME2/HD

The Blackmagic Design ATEM 2 M/E Advanced Panel (model SWATEMSCN21ME2HD) is a professional hardware control panel designed to enhance live production workflows. Key features include:

  • Dual M/E Rowsbhphotovideo.com
  • Independent System Control LCDsbhphotovideo.com
  • Customizable LCD Labelsblackmagicdesign.com
  • High-Quality Controlsbhphotovideo.com
  • Select Bus for Each Rowblackmagicdesign.com
  • Ethernet Connectivitybhphotovideo.com
  • USB-C for Firmware Updatesbhphotovideo.com

These features make the ATEM 2 M/E Advanced Panel a versatile and powerful tool for professionals seeking enhanced control over their live production environments.

The Blackmagic Design ATEM 2 M/E Advanced Panel (model SWATEMSCN21ME2HD) is a professional hardware control panel designed to enhance live production workflows. Key features include:

  • Dual M/E Rowsbhphotovideo.com
  • Independent System Control LCDsbhphotovideo.com
  • Customizable LCD Labelsblackmagicdesign.com
  • High-Quality Controlsbhphotovideo.com
  • Select Bus for Each Rowblackmagicdesign.com
  • Ethernet Connectivitybhphotovideo.com
  • USB-C for Firmware Updatesbhphotovideo.com

These features make the ATEM 2 M/E Advanced Panel a versatile and powerful tool for professionals seeking enhanced control over their live production environments.

Control Panel Features:

  • M/E Rows: 2 Mix/Effect (M/E) rows, each equipped with 20 input buttons, allowing for efficient source selection and management.
  • System Control LCDs: Each M/E row includes an independent system control LCD, providing intuitive access to various settings and parameters.
  • Customizable LCDs: A total of 8 LCDs are available for custom labeling, enabling clear identification of inputs and functions.
  • Select Bus: Both M/E rows feature a dedicated select bus for enhanced control during live productions.

Physical Dimensions:

  • Width: 28.54 inches (72.5 cm)
  • Depth: 19 inches (48.3 cm)
  • Height: 6.53 inches (16.6 cm)
  • Weight: Approximately 24.25 lbs (11 kg)

Power Requirements:

  • Input Voltage: 100 to 240 VAC, allowing for global compatibility.
  • Power Consumption: 150 W

Connectivity:

  • Ethernet: 4 x RJ45 ports supporting 10/100/1000 BaseT for reliable network communication.
  • USB-C: 1 x USB Type-C port designated for firmware updates.

Environmental Specifications:

  • Operating Temperature: 0° to 40° C (32° to 104° F)
  • Storage Temperature: -20° to 60° C (-4° to 140° F)
  • Relative Humidity: 0% to 90% non-condensing
