40 x 12G-SDI Inputs: Supports 8K, UHD, and HD video formats, with 10-bit 4:2:2 color depth.

28 x 12G-SDI Outputs: Multiple outputs for program, preview, and auxiliary channels.

16 x Advanced Keyers: High-quality keying, including chroma and luma keys.

4 x Digital Video Effects (DVEs): Independent processors for picture-in-picture effects and creative transitions.

2 x SuperSource Processors: Create multi-layer compositions with customizable graphics.

4 x Media Players: Store up to 60 stills and 400-frame animations, perfect for video assets and graphics.

Multiview Monitoring: 4 x independent Ultra HD multiviews, with up to 16 views per multiview.

Fairlight Audio Mixer: 156-channel audio mixer with advanced features like EQ, compression, and noise gating.

Talkback System: Integrated communication with production staff, including headset connectors.

USB-C Webcam Output: Enables the switcher to be used as a webcam for streaming and video software.

Control Options: Remote control through ATEM Software Control or optional hardware control panels.

Dual Power Supply: Redundant power supplies for enhanced reliability.

Ethernet Connectivity: Supports remote control via network connections for easy integration into workflows.

40 x 12G-SDI Inputs: Supports 8K, UHD, and HD video formats, with 10-bit 4:2:2 color depth.

28 x 12G-SDI Outputs: Multiple outputs for program, preview, and auxiliary channels.

16 x Advanced Keyers: High-quality keying, including chroma and luma keys.

4 x Digital Video Effects (DVEs): Independent processors for picture-in-picture effects and creative transitions.

2 x SuperSource Processors: Create multi-layer compositions with customizable graphics.

4 x Media Players: Store up to 60 stills and 400-frame animations, perfect for video assets and graphics.

Multiview Monitoring: 4 x independent Ultra HD multiviews, with up to 16 views per multiview.

Fairlight Audio Mixer: 156-channel audio mixer with advanced features like EQ, compression, and noise gating.

Talkback System: Integrated communication with production staff, including headset connectors.

USB-C Webcam Output: Enables the switcher to be used as a webcam for streaming and video software.

Control Options: Remote control through ATEM Software Control or optional hardware control panels.

Dual Power Supply: Redundant power supplies for enhanced reliability.

Ethernet Connectivity: Supports remote control via network connections for easy integration into workflows.

• AI-Powered Enhancements: Equipped with innovative AI features such as AI Gaze Correction, which ensures on-screen talent appears to maintain eye contact with the audience, and AI Keyer for improved chroma keying performance.
• Flexible Licensing Options: Available with either perpetual or subscription licenses, providing flexibility to suit various production needs and budgets. Perpetual licenses include one year of standard support and a three-year Viz Flowics Basic subscription.
• Future-Proof Design: Built to accommodate future advancements in video production technology, ensuring long-term value and adaptability. The system is designed with a roadmap for exciting new features and updates, keeping your production capabilities at the forefront of industry standards.

The TriCaster Vizion TCVIZIONT0IO is an ideal solution for professionals seeking a robust, IP-focused production system with advanced graphics capabilities and AI-driven features, all within a flexible licensing framework.

For a visual overview and demonstration of the TriCaster Vizion, you might find the following video informative:

Video Inputs:

• SDI Video Inputs: 40 x 12G-SDI inputs, each supporting 10-bit 4:2:2 video formats, including UHD 4K, 1080p, 1080i, and 720p.
• Reference Input: Tri-Sync or Black Burst.
• Input Video Format: Supports SDI (10-Bit 4:2:2) in various resolutions and frame rates.

Video Outputs:

• SDI Video Outputs: 28 x 12G-SDI outputs, each supporting 10-bit 4:2:2 video formats.
• Auxiliary Outputs: 24 x 12G-SDI aux outputs.
• Down Converted SDI Program Output: 1 x 12G-SDI output.
• Preview Outputs: Any of the 24 SDI outputs can be configured as preview outputs.

Key Features:

• Upstream Keyers: 16 x ATEM Advanced Chroma Keyers.
• Downstream Keyers: 4 x Chroma, Luma, or DVE keyers.
• Digital Video Effects (DVEs): 4 x independent DVEs for picture-in-picture effects.
• SuperSource Processors: 2 x SuperSource processors for multi-layer compositions.
• Media Players: 4 x media players with fill and key channels, capable of holding up to 60 stills and 400-frame animations.
• Multiview Monitoring: 4 x independent Ultra HD multiviews, each supporting up to 16 views.
• Talkback Support: Built-in talkback with 5-pin XLR headset connector and RJ12 connector for industry-standard systems.

Audio Mixer:

• Channels: 156-channel Fairlight audio mixer.
• Processing: 6-band parametric EQ, compressor, limiter, noise gate, and expander on each input.
• Control: Level and peak metering, master gain control.

Control and Connectivity:

• Control Panel: Front fascia emergency switching, software control via ATEM Software Control, or optional hardware panel.
• Network: Ethernet supports 10/100/1000 BaseT for direct connection or via network.
• USB-C: USB-C connection for webcam output, compatible with video software.

Physical Specifications:

• Dimensions: 19 x 13.26 x 3.54 inches (48.3 x 33.68 x 8.99 cm).
• Weight: 18.52 lbs (8.4 kg).
• Power Supply: Dual internal 100-240V AC 50/60Hz power supplies.
• Power Usage: 255W.

Environmental:

• Operating Temperature: 32.0 to 104.0°F (0.0 to 40.0°C).
• Storage Temperature: -4 to 140°F (-20 to 60°C).
• Operating Humidity: 0 to 90% (non-condensing).
