12G-SDI to Optical Fiber Conversion: Converts 12G-SDI video signals to optical fiber, enabling long-distance transmission of high-quality video.

Supports 4K and HD Video: Transmits high-definition video signals (up to 2160p60) and Ultra HD (4K) over optical fiber for high-quality broadcasting.

Compact Design: Small, portable form factor that’s ideal for both field and studio production environments.

Bidirectional Operation: Supports both input and output for optical fiber, enabling two-way signal transmission.

Low Latency: Ensures minimal delay in video signal transmission, making it suitable for real-time broadcasting and live production applications.

Long-Distance Transmission: Can transmit signals over much longer distances than traditional copper SDI cables, ideal for large studio environments or outdoor broadcast setups.

Built-In Power Supply: Powered by an external 12V power supply (included), ensuring reliable and continuous operation.

Rugged and Reliable: Designed for professional use with durable construction to withstand the demands of high-performance video production environments.

12G-SDI to Optical Fiber Conversion: Converts 12G-SDI video signals to optical fiber, enabling long-distance transmission of high-quality video.

Supports 4K and HD Video: Transmits high-definition video signals (up to 2160p60) and Ultra HD (4K) over optical fiber for high-quality broadcasting.

Compact Design: Small, portable form factor that’s ideal for both field and studio production environments.

Bidirectional Operation: Supports both input and output for optical fiber, enabling two-way signal transmission.

Low Latency: Ensures minimal delay in video signal transmission, making it suitable for real-time broadcasting and live production applications.

Long-Distance Transmission: Can transmit signals over much longer distances than traditional copper SDI cables, ideal for large studio environments or outdoor broadcast setups.

Built-In Power Supply: Powered by an external 12V power supply (included), ensuring reliable and continuous operation.

Rugged and Reliable: Designed for professional use with durable construction to withstand the demands of high-performance video production environments.

Input/Output Ports:

SDI Input: 1 x 12G-SDI input (BNC)

Optical Fiber Input/Output: 1 x Optical Fiber input/output (LC Connector)

Supported Video Standards:

SD Video: 525i59.94, 625i50

HD Video: 720p50, 720p59.94, 720p60; 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60; 1080i50, 1080i59.94, 1080i60

Ultra HD (4K) Video: 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p60

Signal Processing:

SDI Standard: SMPTE 292M, 424M, 2082 (12G-SDI)

Color Precision: 4:2:2

Color Space: YUV

Power Requirements:

Power Supply: 12V DC via external power supply (included)

Power Consumption: Maximum 5W

Operational Voltage Range: 10V to 18V DC

Environmental:

Operating Temperature: 0°C to 40°C (32°F to 104°F)

Storage Temperature: -20°C to 60°C (-4°F to 140°F)

Relative Humidity: 0% to 90%, non-condensing

Physical Specifications:

Dimensions: 92 x 72 x 28 mm (3.62 x 2.83 x 1.1 inches)

Weight: 130 g (4.59 oz)
