1. Audio to SDI Conversion: Converts analog audio (balanced or unbalanced) or AES/EBU digital audio into SDI signals, enabling audio embedding for SDI video workflows.
2. Dual Audio Channels: Supports embedding two channels of balanced audio (via XLR or RCA) or AES/EBU audio into the SDI signal.
3. SD/HD Video Compatibility: Works with both SD (Standard Definition) and HD (High Definition) video formats for broad compatibility in various production environments.
4. 12-bit Audio Processing: Supports 12-bit audio for high-quality signal conversion and embedding into the SDI stream.
5. Compact and Portable: Small, lightweight design ideal for both studio and field production use, ensuring easy integration into any setup.
6. Plug-and-Play Operation: No software configuration required; simply connect the audio source and SDI output, and it's ready to go.
7. Power Supply Included: Powered by a standard 12V power supply, ensuring stable and reliable operation.
8. Rugged and Durable: Built to withstand the demands of professional video production environments.

1. Audio to SDI Conversion: Converts analog audio (balanced or unbalanced) or AES/EBU digital audio into SDI signals, enabling audio embedding for SDI video workflows.
2. Dual Audio Channels: Supports embedding two channels of balanced audio (via XLR or RCA) or AES/EBU audio into the SDI signal.
3. SD/HD Video Compatibility: Works with both SD (Standard Definition) and HD (High Definition) video formats for broad compatibility in various production environments.
4. 12-bit Audio Processing: Supports 12-bit audio for high-quality signal conversion and embedding into the SDI stream.
5. Compact and Portable: Small, lightweight design ideal for both studio and field production use, ensuring easy integration into any setup.
6. Plug-and-Play Operation: No software configuration required; simply connect the audio source and SDI output, and it's ready to go.
7. Power Supply Included: Powered by a standard 12V power supply, ensuring stable and reliable operation.
8. Rugged and Durable: Built to withstand the demands of professional video production environments.

Input Ports:

Analog Audio Input: 2 x Balanced (XLR) or Unbalanced (RCA) audio inputs

AES/EBU Digital Audio Input: 1 x 2-channel AES/EBU audio input (BNC)

Output Ports:

SDI Output: 1 x 3G-SDI output (BNC)

Supported Video Standards:

SD Video: 525i59.94, 625i50

HD Video: 720p50, 720p59.94, 720p60; 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60; 1080i50, 1080i59.94, 1080i60

Audio Format:

Balanced Audio: 2 channels (XLR or RCA)

Digital Audio (AES/EBU): 2 channels (BNC)

Signal Processing:

Audio Processing: 12-bit audio embedding into SDI

Power Requirements:

Power Supply: 12V DC via external power supply (included)

Power Consumption: Maximum 5W

Operational Voltage Range: 10V to 18V DC

Environmental:

Operating Temperature: 0°C to 40°C (32°F to 104°F)

Storage Temperature: -20°C to 60°C (-4°F to 140°F)

Relative Humidity: 0% to 90%, non-condensing

Physical Specifications:

Dimensions: 92 x 72 x 28 mm (3.62 x 2.83 x 1.1 inches)

Weight: 130 g (4.59 oz)
