The Blackmagic Design Teranex Mini SDI to HDMI 8K HDR Converter (model CONVN8TRM/AA/SDIH) offers the following features:

• 8K HDMI Monitoringbhphotovideo.com
• Quad HDMI Outputsblackmagicdesign.com
• Built-in Down Converterblackmagicdesign.com
• HDR Supportblackmagicdesign.com
• 33-Point 10-Bit RGB LUTsblackmagicdesign.com
• Integrated Scopesblackmagicdesign.com
• Monitor Calibrationbhphotovideo.com
• Multi-Rate Supportblackmagicdesign.com
• Embedded Audio Supportblackmagicdesign.com
• Advanced 8K Monitoring Solutionblackmagicdesign.com

These features make the Teranex Mini SDI to HDMI 8K HDR Converter a versatile and powerful tool for professionals requiring high-resolution monitoring and precise color management in their workflows.

The Blackmagic Design Teranex Mini SDI to HDMI 8K HDR Converter (model CONVN8TRM/AA/SDIH) offers the following features:

• 8K HDMI Monitoringbhphotovideo.com
• Quad HDMI Outputsblackmagicdesign.com
• Built-in Down Converterblackmagicdesign.com
• HDR Supportblackmagicdesign.com
• 33-Point 10-Bit RGB LUTsblackmagicdesign.com
• Integrated Scopesblackmagicdesign.com
• Monitor Calibrationbhphotovideo.com
• Multi-Rate Supportblackmagicdesign.com
• Embedded Audio Supportblackmagicdesign.com
• Advanced 8K Monitoring Solutionblackmagicdesign.com

These features make the Teranex Mini SDI to HDMI 8K HDR Converter a versatile and powerful tool for professionals requiring high-resolution monitoring and precise color management in their workflows.

Connections:

• SDI Video Inputs: 4 x 12G-SDI (BNC) with auto-switching for HD, 2K, 4K, and 8K formats; supports dual and quad link 12G-SDI for 8K.
• SDI Video Outputs: 4 x 12G-SDI loop-through outputs (BNC).
• HDMI Video Outputs: 4 x HDMI 2.0 Type A connectors, supporting single-link HD, UHD, and 4K, or quad-link 4320p60 for 8K.
• Analog Audio Outputs: 2 channels via RCA connectors.
• USB Port: 1 x USB Type-C for updates, configuration, and monitor calibration.
• Ethernet: 1 x Gigabit Ethernet port for network management and control.

Video Standards:

• HD Video Standards: 720p50, 720p59.94, 720p60; 1080i50, 1080i59.94, 1080i60; 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60.
• 2K Video Standards: 2K DCI 23.98p, 24p, 25p; 2K DCI 23.98PsF, 24PsF, 25PsF.
• Ultra HD Video Standards: 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60.
• 4K DCI Video Standards: 4K DCI 23.98p, 24p, 25p, 29.97p, 30p.
• 8K Video Standards: 4320p23.98, 4320p24, 4320p25, 4320p29.97, 4320p30, 4320p50, 4320p59.94, 4320p60.

SDI Compliance:

• SMPTE 2082-1, 2082-10, 2081-1, 2081-10, 425M, 424M, 292M, 259M, and 2084 for HDR.

SDI Video Rates:

• 1.5G, 3G, 6G, and 12G-SDI.

SDI Video Sampling:

• 4:2:2 and 4:4:4.

SDI Color Precision:

• 10-bit 4:2:2 and 4:4:4.

SDI Color Space:

• YUV and RGB.

HDMI Color Space:

• Rec. 709, Rec. 2020.

HDMI Color Precision:

• YUV 4:2:2 and RGB 4:4:4 in HD, 2K, 4K, and 8K.

Multi-Rate Support:

• 1.5G, 3G, 6G, 12G, 2SI Dual Link 12G-SDI, 2SI Quad Link 12G-SDI, Square Division Quad Link 12G-SDI.

Embedded Audio Support:

• 16 channels on all SDI loop outputs; 8 channels on HDMI outputs.

Scopes:

• Waveform, RGB/YUV Parade, Vectorscope, Histogram.

Display Modes:

• Two scope displays with image overlay and adjustable opacity; waveform and parade with standard and HDR grids.

3D LUT Support:

• 33-point 10-bit RGB LUTs; two independent LUTs can be loaded and selected via the front panel.

HDR Support:

• PQ and HLG formats; ST2108-1, ST2084, and ST425 standards; supports Rec. 2020 and Rec. 709 color spaces; 100% DCI-P3 coverage.

Monitor Calibration:

• Compatible with SpectraCal C6, X-Rite i1 Display Pro, and Klein K10-A probes for automatic display alignment.

Software Control:

• Compatible with Mac OS X and Windows for updates and configuration via USB or Ethernet.

Power Requirements:

• Power Supply: Built-in international AC power supply with IEC C14 inlet; 100–240V AC input.
• Power Consumption: 25W.

Environmental Specifications:

• Operating Temperature: 0° to 40°C (32° to 104°F).
• Storage Temperature: -20° to 60°C (-4° to 140°F).
• Relative Humidity: 0% to 90% non-condensing.

Dimensions:

• 210 x 44 x 176 mm.

Weight:

• 1.2 kg.

What's Included:

• Teranex Mini SDI to HDMI 8K HDR Converter.
• Welcome wallet with QR code for software download.

Warranty:

• 3-Year Limited Manufacturer’s Warranty.
