Key Features:

• Dual 8" LCD Monitors: Each monitor offers an 800 x 480 resolution, providing clear and detailed video display.
• Auto-Sensing SDI Inputs: Automatically detects and switches between SD, HD, and 6G-SDI video formats, ensuring compatibility with various video sources.
• Independent Waveform Monitoring:Blackmagic Design
• Loop-Through SDI Outputs: Includes loop-through SDI outputs for both inputs, allowing for signal distribution to additional devices without signal degradation.
• Tally Support:Blackmagic Design
• Software Control: Supports remote adjustments via Ethernet, enabling centralized control and configuration of multiple units.
• Rack-Mountable Design: Designed to fit into a 3RU rack space, facilitating easy integration into existing broadcast and production racks.
• Ultra-Thin Profile: With a depth of less than 1.5 inches, the SmartScope Duo 4K 2 is ideal for space-constrained environments and portable setups.

Key Features:

• Dual 8" LCD Monitors: Each monitor offers an 800 x 480 resolution, providing clear and detailed video display.
• Auto-Sensing SDI Inputs: Automatically detects and switches between SD, HD, and 6G-SDI video formats, ensuring compatibility with various video sources.
• Independent Waveform Monitoring:Blackmagic Design
• Loop-Through SDI Outputs: Includes loop-through SDI outputs for both inputs, allowing for signal distribution to additional devices without signal degradation.
• Tally Support:Blackmagic Design
• Software Control: Supports remote adjustments via Ethernet, enabling centralized control and configuration of multiple units.
• Rack-Mountable Design: Designed to fit into a 3RU rack space, facilitating easy integration into existing broadcast and production racks.
• Ultra-Thin Profile: With a depth of less than 1.5 inches, the SmartScope Duo 4K 2 is ideal for space-constrained environments and portable setups.

Key Specifications:

Display:

• Dual 8-inch LCD screens with 800 x 480 resolution.
• Supports SD, HD, Ultra HD, and 4K video formats.

Inputs:

• 2 x 6G-SDI inputs with auto-sensing and selection.
• Reclocked loop-through SDI outputs for each input.

Scopes:

• Waveform, Vectorscope, RGB Parade, YUV Parade, Histogram, Audio Phase, and Level.

Audio Monitoring:

• 16 channels of embedded SDI audio monitoring.

Tally:

• 9-pin D connector for tally support.

Control:

• USB 2.0 for software updates.
• Ethernet for configuration and control.

Power Requirements:

• 12V universal power supply included.
• Power consumption: < 20 Watts.
• Operational voltage range: 12V - 15V.

Physical Dimensions:

• 3RU rack-mountable.
• Dimensions: 19.0 x 6.0 x 1.7 inches (482.6 x 152.4 x 43.2 mm).
• Weight: 5.07 lbs (2.3 kg).
