The Key Features of the Blackmagic Design URSA Broadcast G2 Camera:

6K DIGITAL FILM SENSOR

• Super 35mm 6K Sensor: Captures stunning, detailed images with a native resolution of 6144 x 3456.
• 13 Stops of Dynamic Range: Ensures excellent highlight and shadow detail for a cinematic look.
• Dual Native ISO: Up to 25,600 ISO, delivering impressive low-light performance.
• Global Shutter-Like Functionality: Minimizes rolling shutter artifacts, ideal for fast-moving subjects.

ADVANCED IMAGE PROCESSING

• Blackmagic RAW: Efficient, high-quality codec for maximum flexibility in post-production.
• ProRes Support: Broadcast-standard recording format for compatibility with existing workflows.
• Color Science: Blackmagic’s 5th Generation Color Science ensures accurate skin tones and cinematic color rendering.

HIGH FRAME RATE SUPPORT

• Record at high frame rates for creative slow-motion effects:

FLEXIBLE RECORDING OPTIONS

• Dual card slots for flexible media storage:
• Record simultaneously to multiple formats or cards for redundancy and backup.

BUILT-IN OPTICAL LOW PASS FILTER (OLPF)

• Reduces moiré and aliasing for sharper, cleaner images.
• Enhances the performance of the 6K sensor by maintaining color accuracy and fine detail.

VERSATILE LENS MOUNT

• B4 Lens Mount: Included as standard for broadcast lenses.
• Optional PL, EF, or F mounts available for compatibility with a wide range of cinema and photography lenses.
• Electronic Lens Control: Supports iris, focus, and zoom adjustments for compatible lenses.

BUILT-IN MOTORIZED ND FILTERS

• Neutral Density (ND) Filters: 1/4, 1/16, and 1/64 stops for precise control of exposure in varying lighting conditions.
• Infrared Compensation: Ensures accurate color reproduction even with heavy filtration.

CONNECTIVITY OPTIONS

• 12G-SDI Outputs
• USB-C Expansion Port
• Timecode and Reference Input: Sync with multi-camera systems for live production.
• Ethernet Support: Enables remote camera control and operation in IP-based workflows.

BROADCAST-READY FEATURES

• Built-in Tally Light: Indicates live recording status for studio or broadcast production.
• Intercom & Talkback: Connects directly to ATEM switchers for seamless studio operation.
• Remote Control: Fully controllable via Blackmagic ATEM hardware or software.

AUDIO FEATURES

• Dual XLR Inputs: With phantom power support for professional microphones.
• High-Quality Internal Microphones: Built-in stereo microphones for on-location audio capture.
• Headphone Output: 3.5mm jack for monitoring.

MONITORING AND DISPLAY

• Fold-Out LCD Touchscreen:
• Custom LUT Support: Apply custom LUTs for previewing looks during shoots.
• Focus Assist Tools: Includes peaking, zoom, and overlays for precise focusing.

DURABLE, PROFESSIONAL BUILD

• Rugged Magnesium Alloy Body: Built for durability and portability in challenging environments.
• Compact and Lightweight: Ideal for handheld use or mounted rigs.
• Ergonomic Design: Well-balanced body with intuitive button layout for easy operation.

PROFESSIONAL WORKFLOW INTEGRATION

• Live Production Integration: Works seamlessly with ATEM switchers for live event production.
• DaVinci Resolve Studio:
• Downscaling Capability: Capture in 6K and output to 4K or HD for exceptional quality.

POWER OPTIONS

• 12V XLR Power Input: For studio setups or external power sources.
• Battery Plate Compatibility: Supports V-Mount or Gold Mount batteries for field production.
• Low Power Consumption: Efficient power usage for extended shoots.

APPLICATIONS

• Ideal for live broadcasts, cinematic productions, documentaries, and live streaming.
• Adaptable for multi-camera setups with robust connectivity and control options.

The Detailed Specifications for the Blackmagic Design URSA Broadcast G2 Camera:

CAMERA SPECIFICATIONS

• Sensor Size: Super 35mm 6K sensor
• Resolution: 6144 x 3456
• Dynamic Range: 13 stops
• Dual Native ISO: Up to ISO 25,600
• Frame Rates:
• Lens Mount: B4 mount (included), optional PL, EF, and F mounts
• Built-In ND Filters:

RECORDING FORMATS

• Codecs: Blackmagic RAW (BRAW), ProRes
• Resolutions Supported:
• File Formats:
• Frame Rates:

RECORDING MEDIA

• Media Slots:
• Simultaneous Recording: Multiple media options for redundancy

CONNECTIVITY

• 12G-SDI Outputs:
• USB-C: High-speed for SSD recording and firmware updates
• Timecode Input/Output: For sync in multi-camera setups
• Reference Input: Genlock support
• Ethernet: For remote camera control
• Audio Inputs:

DISPLAY

• Built-In LCD: 4-inch fold-out touchscreen monitor
• Resolution: Full HD
• Custom LUT Support: Apply LUTs for monitoring and previewing looks
• Focus Assist Tools: Peaking, zoom, and overlays

AUDIO

• Integrated Microphones: High-quality stereo microphones
• XLR Inputs: Dual balanced XLR with phantom power for professional microphones
• Headphone Output: 3.5mm stereo jack

BUILD & DIMENSIONS

• Material: Magnesium alloy body for durability
• Dimensions (Approx.): 9.3 x 5.8 x 5.5 inches
• Weight: 5.2 lbs (body only)
• Operating Temperature: 0 to 40°C (32° to 104°F)

POWER

• Power Input: 12V XLR input for studio power
• Battery Support: V-Mount or Gold Mount compatible (battery plate sold separately)
• Power Consumption: Approximately 30-48W depending on usage

INCLUDED SOFTWARE

• DaVinci Resolve Studio: Full version included for editing, grading, VFX, and delivery

USE CASES

• Ideal for broadcast production, live streaming, cinematic shooting, and multi-camera setups.
