Ultra-Compact Design – Small, lightweight form factor ideal for studio, broadcast, and live production.

4K Ultra HD Resolution – Captures 3840 x 2160 resolution video with 13 stops of dynamic range for high-quality imaging.

Micro Four Thirds (MFT) Lens Mount – Compatible with a wide range of MFT lenses for flexible shooting options.

12G-SDI & HDMI Outputs – Supports 12G-SDI and HDMI 2.0 for seamless integration with professional production equipment.

USB-C Recording & Streaming – Allows direct recording to USB-C drives in Blackmagic RAW and supports live streaming.

Remote Camera Control – Can be controlled remotely via SDI, HDMI, or USB Ethernet adapters for flexible operation.

Built-in Color Correction – Features integrated color correction tools for accurate image adjustments.

Auto-Focus Support – Compatible with select lenses for auto-focus functionality.

Professional Audio Input – Includes a 3.5mm stereo audio input, which can also be used for timecode input.

High Dynamic Range (HDR) Support – Delivers rich colors and details in various lighting conditions.

Ultra-Compact Design – Small, lightweight form factor ideal for studio, broadcast, and live production.

4K Ultra HD Resolution – Captures 3840 x 2160 resolution video with 13 stops of dynamic range for high-quality imaging.

Micro Four Thirds (MFT) Lens Mount – Compatible with a wide range of MFT lenses for flexible shooting options.

12G-SDI & HDMI Outputs – Supports 12G-SDI and HDMI 2.0 for seamless integration with professional production equipment.

USB-C Recording & Streaming – Allows direct recording to USB-C drives in Blackmagic RAW and supports live streaming.

Remote Camera Control – Can be controlled remotely via SDI, HDMI, or USB Ethernet adapters for flexible operation.

Built-in Color Correction – Features integrated color correction tools for accurate image adjustments.

Auto-Focus Support – Compatible with select lenses for auto-focus functionality.

Professional Audio Input – Includes a 3.5mm stereo audio input, which can also be used for timecode input.

High Dynamic Range (HDR) Support – Delivers rich colors and details in various lighting conditions.

Camera Features:

• Effective Sensor Size: 17.78mm x 10mm (Four Thirds)
• Lens Mount: Active Micro Four Thirds (MFT) Mount
• Lens Control: Iris, focus, and zoom control on supported lenses
• Dynamic Range: 13 stops
• Dual Native ISO: 0dB and 18dB gain
• Sensitivity at 0dB Gain: f/11 at 2160p59.94; f/12 at 2160p50; measured at 2,000 lux with 89.9% reflectance
• Signal to Noise Ratio: 63dB for 2160p

Shooting Resolutions:

• 3840 x 2160 (Ultra HD) up to 60 fps

Frame Rates:

• 23.98, 24, 25, 29.97, 30, 50, 59.94, and 60 fps
• Off-speed frame rates up to 60 fps in Ultra HD

Focus:

• Auto-focus available with compatible lenses

Mounting Options:

• 1 x 1/4-inch mount on top
• 3 x 1/4-inch mounts on bottom

Connections:

• SDI Video Inputs: 1
• SDI Video Outputs: 1
• SDI Rates: 3G, 6G, 12G
• HDMI 2.0 Video Outputs: 1
• Analog Audio Input: 1 x 3.5mm stereo input (can also be used for timecode input)
• Reference Input: Program SDI input on camera

Audio:

• Microphone: Integrated stereo microphone

Standards:

• HD Video Standards: 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
• Ultra HD Video Standards: 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
• SDI Compliance: SMPTE 292M, SMPTE 424M, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1, SMPTE 2082-10
• SDI Audio Sampling: 48 kHz, 24-bit
• HDMI Audio Sampling: 48 kHz, 24-bit

Media:

• Media: 1 x USB-C 3.1 Gen 1 expansion port for external media for recording Blackmagic RAW
• Media Format: Can format media to ExFAT (Windows/Mac) or HFS+ (Mac) file systems
• Supported Codecs: Blackmagic RAW Constant Bitrate 3:1, 5:1, 8:1, 12:1; Blackmagic RAW Constant Quality Q0, Q1, Q3, Q5

Storage Features:

• Storage Type: 1 x USB-C 3.1 Gen 1 expansion port for external media
• Recording Formats: Blackmagic RAW 3:1, 5:1, 8:1, 12:1, Q0, Q1, Q3, Q5 in Ultra HD 3840 x 2160 at the selected frame rate
• Storage Rates: (Based on 30 fps)

Control:

• External Control: Remote camera control over SDI, HDMI, or USB Ethernet with suitable adapter

Power Requirements:

• Power Supply: 1 x 12V DC input

Environmental Specifications:

• Operating Temperature: 32° to 104° F (0° to 40° C)
• Storage Temperature: -4° to 113° F (-20° to 45° C)
• Relative Humidity: 0% to 90% non-condensing
