6K Super 35 Sensor – Captures 6144 x 3456 resolution video with 13 stops of dynamic range for professional-quality imaging.

Canon EF Lens Mount – Supports a wide range of interchangeable EF lenses for enhanced creative control.

Built-in ND Filters – Features motorized IR ND filters (Clear, 2-stop, 4-stop, 6-stop) for precise exposure adjustments.

7-inch HDR Touchscreen Display – A 2000-nit, 1920 x 1200 LCD for high visibility and intuitive touchscreen controls.

Dual Native ISO – Provides exceptional low-light performance with 0dB and 18dB gain settings for reduced noise.

12G-SDI & HDMI Connectivity – Supports 12G-SDI output and HDMI 2.0 output for seamless broadcast and live production integration.

XLR Audio Inputs – Two balanced XLR inputs with phantom power support for professional microphones and line-level audio sources.

USB-C Recording & Live Streaming – Allows recording directly to USB-C drives in Blackmagic RAW and supports live streaming via Ethernet.

Talkback & Tally Support – Includes 5-pin XLR talkback connectivity and SDI tally indicators for live production communication.

Lightweight & Portable Design – Optimized for broadcast production, live events, and streaming, with a compact yet professional form factor.

6K Super 35 Sensor – Captures 6144 x 3456 resolution video with 13 stops of dynamic range for professional-quality imaging.

Canon EF Lens Mount – Supports a wide range of interchangeable EF lenses for enhanced creative control.

Built-in ND Filters – Features motorized IR ND filters (Clear, 2-stop, 4-stop, 6-stop) for precise exposure adjustments.

7-inch HDR Touchscreen Display – A 2000-nit, 1920 x 1200 LCD for high visibility and intuitive touchscreen controls.

Dual Native ISO – Provides exceptional low-light performance with 0dB and 18dB gain settings for reduced noise.

12G-SDI & HDMI Connectivity – Supports 12G-SDI output and HDMI 2.0 output for seamless broadcast and live production integration.

XLR Audio Inputs – Two balanced XLR inputs with phantom power support for professional microphones and line-level audio sources.

USB-C Recording & Live Streaming – Allows recording directly to USB-C drives in Blackmagic RAW and supports live streaming via Ethernet.

Talkback & Tally Support – Includes 5-pin XLR talkback connectivity and SDI tally indicators for live production communication.

Lightweight & Portable Design – Optimized for broadcast production, live events, and streaming, with a compact yet professional form factor.

Camera Features:

• Effective Sensor Size: 23.10mm x 12.99mm (Super 35)
• Lens Mount: Active EF mount
• Lens Control: Iris, focus, and zoom control on supported lenses
• Dynamic Range: 13 stops
• Dual Native ISO: 0dB and 18dB gain
• Sensitivity at 0dB Gain: f/11 at 2160p59.94; f/12 at 2160p50; measured at 2,000 lux with 89.9% reflectance
• Signal to Noise Ratio: 64.62dB for 2160p (Ultra HD scaled from 5.3K)

Recording Resolutions:

• 6144 x 3456 (6K) up to 50 fps
• 6144 x 2560 (6K 2.4:1) up to 60 fps
• 5376 x 3024 (5.3K 16:9) up to 60 fps
• 3840 x 2160 (Ultra HD) up to 60 fps

Frame Rates:

• Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94, and 60 fps supported
• Off-speed frame rates 5–50 fps in 6K, and 5–60 fps for all other recording resolutions

Built-in ND Filters:

• Four-position ND filter with clear, 2-stop, 4-stop, and 6-stop IR ND filters

Focus:

• Auto-focus available using compatible lenses

Screen:

• Dimensions: 7-inch
• Resolution: 1920 x 1200
• Type: LCD capacitive touchscreen
• Brightness: 2000 nits

Controls:

• Touchscreen camera settings and menus with rotary settings dial, program button, F1, F2, and F3 assignable function buttons, brightness, contrast, and peaking dials

Mounting Options:

• 2 x 1/4-inch tripod mounts
• 1 x 3/8-inch tripod mount

Connections:

• SDI Video Inputs: 1
• SDI Video Outputs: 1
• SDI Rates: 1.5G, 3G, 6G, 12G
• HDMI 2.0 Video Outputs: 1
• Analog Audio Input: 2 x XLR analog switchable between mic and line levels with phantom power support; 1 x 3.5mm stereo input (can also be used for timecode input)
• Analog Audio Output: 1 x 5-pin XLR for talkback headset; 1 x 3.5mm TRRS mini jack for headphones with mic
• Computer Interface: 2 x USB Type‑C 3.1 Gen 1 (up to 5Gb/s) expansion ports for external recording and focus/zoom demand connection; software updates using USB‑C Port A

Audio:

• Microphone: Integrated stereo microphone
• Built-in Speaker: 1 x mono speaker

Recording Formats:

• Blackmagic RAW 3:1, 5:1, 8:1, 12:1, Q0, Q1, Q3, and Q5 in 6K (6144 x 3456), 6K 2.4:1 (6144 x 2560), 5.3K 16:9 (5376 x 3024), Ultra HD (3840 x 2160) at the selected frame rate

Storage Rates:

• Storage rates based on 30 frames per second
• 6144 x 3456 (6K):

Power Requirements:

• Power Supply: 1 x 4-pin XLR 12V DC input; 1 x barrel 12V DC input

Environmental Specifications:

• Operating Temperature: 32° to 104° F (0° to 40° C)
• Storage Temperature: -4° to 113° F (-20° to 45° C)
• Relative Humidity: 0% to 90% non-condensing
