Data Video DAC-8PA HDMI to 12G-SDI Converter with Audio Embedding

Data Video DAC-8PA 4K HDMI to 12G-SDI Converter with Audio Embedding

by Data Video
Availability:
In stock 3-5 days
$219.00 - $219.00
$219.00
$219.00 - $219.00
$219.00

SKU: DAC8PA
  • Overview
  • Features
  • Specifications

The Data Video DAC-8PA is a high-performance signal converter designed for professional video production and broadcast environments. It seamlessly converts 4K HDMI signals to 12G-SDI outputs while embedding balanced analog or AES/EBU audio into the SDI stream. With its compact form factor and robust build, the DAC-8PA is an essential tool for AV professionals who need reliable, real-time signal conversion in a variety of production scenarios.

The Key Features of the Data Video DAC8A:

  • Converts 4K HDMI video to 12G/6G/3G/HD-SDI outputs
  • Supports embedded audio from HDMI or external audio sources
  • Selectable analog or AES/EBU audio embedding
  • Integrated audio level control and channel selection
  • Compact and durable metal housing for rugged use
  • Auto-detects and supports multiple video resolutions
  • Real-time, latency-free signal conversion
  • Ideal for professional broadcasting, live events, and AV installations

The Detailed Specifications for the Data Video DAC8PA:

  • Input: 1 x HDMI Type A (up to 4K 60p)
  • Output: 2 x 12G-SDI BNC
  • Audio Inputs: 2 x XLR (Analog or AES/EBU switchable)
  • Supported Video Formats: 2160p (60/59.94/50/30/29.97/25/24/23.98), 1080p/i, 720p
  • Audio Embedding: Analog/AES selectable via DIP switches
  • Video Conversion: Real-time, zero latency
  • Power Supply: DC 12V with locking connector
  • Dimensions: 129 x 104 x 30 mm
  • Weight: Approx. 0.5 kg
  • Operating Temperature: 0°C to 40°C (32°F to 104°F)
