Data Video DAC-8P 4K HDMI to 12G-SDI Converter
Availability:
In stock 3-5 days
Original price
$549.00
-
Original price
$549.00
Original price
$549.00
$549.00
-
$549.00
Current price
$549.00
| /
The Data Video DAC-8P 4K HDMI to 12G-SDI Converter is a professional-grade video converter designed for high-end production environments. This compact device converts HDMI 2.0 signals to dual 12G-SDI outputs, supporting ultra-high-definition 4K resolution at 60 frames per second. Ideal for broadcast studios, OB vans, and live event production, the DAC-8P delivers robust signal integrity with low latency and crystal-clear image quality. Built with a rugged metal chassis and versatile mounting options, it ensures durability and adaptability in the field or studio.
The Key Features of the Data Video DAC8P-4K:
- Converts HDMI 2.0 signals to dual 12G-SDI outputs
- Supports up to 4K60p resolution for ultra-clear video
- Automatic signal detection and conversion
- Low-latency signal processing for real-time applications
- Compact metal housing for durability and portability
- Ideal for professional broadcasting and live events
- Supports embedded audio pass-through
- Locking power connector for secure operation
The Detailed Specifications for the Data Video DAC8P-4K:
- Input Interface: 1 x HDMI 2.0 Type A
- Output Interface: 2 x 12G-SDI BNC
- Supported Resolutions: Up to 4096x2160p @ 60fps
- Audio Support: Embedded HDMI audio pass-through
- Power Input: 12V DC with locking connector
- Power Consumption: Approx. 6.72W
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Dimensions: 104mm x 71mm x 28mm
- Weight: Approx. 280g (0.62 lbs)
- Mounting Options: Integrated thread holes for bracket or rack mount
