Data Video DAC-9P HDMI to SDI Video Converter – Compact Broadcast-Quality Signal Conversion

Data Video DAC-9P HDMI to SDI Converter

by Data Video
Availability:
In stock 3-5 days
$329.00 - $329.00
$329.00
$329.00 - $329.00
$329.00

SKU: DAC9P
  • Overview
  • Features
  • Specifications

The Data Video DAC9P is a compact and reliable HDMI to SDI converter designed for professional video environments. This high-quality converter allows seamless integration of HDMI sources into SDI workflows, making it perfect for broadcasting, live production, and studio setups. With automatic resolution detection and embedded audio support, the DAC9P delivers a streamlined signal conversion without loss of quality. Its loop-through HDMI output and rugged metal housing ensure flexibility and durability for demanding applications.

The Key Features of the Data Video DAC9P:

  • Converts HDMI signal to professional-grade SDI output
  • Supports resolutions up to 1080p60
  • Embedded audio supported up to 8 channels
  • HDMI loop-through for monitoring or daisy-chaining
  • Automatic input resolution detection
  • Durable metal housing for professional use
  • Compact and lightweight for easy integration
  • Locking power connector for secure installation

The Detailed Specifications for the Data Video DAC9P:

  • Input: 1 x HDMI Type A
  • Output: 2 x SDI (3G/HD/SD-SDI), 1 x HDMI Loop-through
  • Supported Video Resolutions: 480i to 1080p60
  • Audio Support: 8-channel embedded audio (48kHz)
  • SDI Standards: SMPTE 425M, 292M, 259M-C
  • Power: 12V DC (locking connector)
  • Power Consumption: 3.6W
  • Dimensions: 94.5 x 80 x 29 mm
  • Weight: 160g
  • Operating Temperature: 0°C to 40°C (32°F to 104°F)
