Konvision KUM-1810D-IP25G 18.4 inch 4K HDR ST2110 IP broadcast monitor with 25G IP connectivity

Konvision 55" 4K/8K HDR ST2110 IP Monitor

by Konvision
Availability:
In stock 3-5 days
Do you have questions about pricing?
📞 416-690-1690
✉️ info@videolink.ca
Trusted by broadcasters, venues, and production teams across Canada.

SKU: KXM-5510M-IP25G

  • Overview
  • Features
  • Specifications

The Konvision KXM-5510M-IP25G is a 55-inch 4K/8K HDR professional reference monitor designed for high-end broadcast, live production, and color grading applications. Featuring a Mini-LED backlight with advanced local dimming, it delivers exceptional contrast, deep blacks, and peak brightness up to 1500 nits for accurate HDR monitoring. Its wide color gamut and precise image processing ensure reliable performance in color-critical workflows.

Engineered for modern IP-based production environments, the monitor supports SMPTE ST2110 standards via dual SFP28 fiber interfaces, enabling high-bandwidth, uncompressed video, audio, and metadata transmission. It also integrates seamlessly into hybrid infrastructures with 12G-SDI, 3G-SDI, and HDMI connectivity, along with IP-to-SDI conversion capabilities. Advanced monitoring tools, quad-view functionality, and 3D LUT calibration make it ideal for shading, mastering, and signal analysis across 4K and emerging 8K workflows.

The Key Features of the Konvision KXM-5510M-IP25G:

  • 55-inch UHD 4K display with support for advanced 8K workflows
  • Mini-LED backlight with 2304-zone local dimming for superior contrast
  • High brightness up to 1500 cd/m² for HDR production environments
  • Ultra-high contrast ratio up to 1,000,000:1 for deep blacks and highlight detail
  • Wide color gamut with up to 98% DCI-P3 and ≥80% BT.2020 coverage
  • Dual SFP28 interfaces for SMPTE ST2110 IP workflows
  • Supports ST2110-10/20/30/40 standards for video, audio, and metadata
  • Optional ST2022-7 hitless failover support for redundant IP systems
  • IP to 12G-SDI conversion output for flexible signal routing
  • 2 x 12G-SDI and 2 x 3G-SDI inputs with loop outputs
  • Supports 4K single-link and quad-link formats including SQD and 2SI
  • HDMI 2.0 input for 4K monitoring workflows
  • 12-bit video processing for accurate color reproduction with zero latency
  • HDR support for HLG and ST2084 PQ with multiple EOTF options
  • 3D LUT calibration compatible with ColourSpace and Calman
  • Quad-view mode with mixed signal formats and independent settings
  • Advanced monitoring tools including waveform, vectorscope, and histogram
  • False color, zebra, focus assist, HDR analysis, and highlight monitoring tools
  • Genlock support with black burst or tri-level sync
  • Payload ID recognition for automatic color space and HDR matching
  • Robust aluminum housing with dual power inputs and built-in speakers

The Detailed Specifications for the Konvision KXM-5510M-IP25G:

  • Model: KXM-5510M-IP25G
  • Display Size: 55 inches
  • Resolution: 3840 x 2160
  • Aspect Ratio: 16:9
  • Viewing Angle: 178° horizontal / 178° vertical
  • Panel Type: IPS LCD with Mini-LED backlight
  • Local Dimming: 2304 zones
  • Brightness: Up to 1500 cd/m²
  • Contrast Ratio: Up to 1,000,000:1
  • Color Gamut: ≥80% BT.2020, up to 98% DCI-P3
  • Video Processing: 12-bit
  • IP Interfaces: 2 x SFP28 fiber interfaces
  • IP Standards: ST2110-10, ST2110-20, ST2110-30, ST2110-40
  • Optional Redundancy: ST2022-7 hitless failover
  • SDI Inputs: 2 x 12G/6G/3G/HD/SD-SDI, 2 x 3G/HD/SD-SDI
  • SDI Outputs: 2 x 12G/6G/3G/HD/SD-SDI, 2 x 3G/HD/SD-SDI
  • IP to SDI Output: ST2110 IP to 12G-SDI output
  • HDMI Input: 1 x HDMI 2.0
  • Supported Formats: Up to 4096 x 2160 at 60p
  • Quad-Link Support: SQD and 2SI
  • Color Spaces: Rec.709, EBU, DCI-P3, DCI-P3 D65, Rec.2020
  • Gamma Options: 2.0, 2.2, 2.4, 2.6
  • HDR Support: HLG and ST2084 PQ
  • Calibration: 3D LUT via USB/Ethernet
  • Analysis Tools: Waveform, vectorscope, histogram, HDR tools
  • Monitoring Tools: False color, zebra, focus assist, highlight check
  • Audio Input: 16-channel embedded SDI audio, HDMI audio
  • Audio Output: 3.5 mm headphone jack
  • Built-in Speakers: 2 x 3W
  • Control: GPI, RS422, Ethernet control
  • Power Supply: AC 100-240V, 50/60Hz and DC input
  • Power Consumption: ≤500W
  • Mounting: VESA 200 x 200 mm / 400 x 400 mm
  • Net Weight: Approx. 32.5 kg
  • Operating Temperature: -10°C to 50°C
  • Included Accessories: Power cord and desktop stand
