Lectrosonics - SMDWB Wideband Beltpack Transmitter (A1: 470 to 537 MHz) (SMDWB-A1)
Original price
$2,866.00
-
Original price
$2,866.00
Original price
$2,866.00
$2,866.00
-
$2,866.00
Current price
$2,866.00
| /
The Lectrosonics SMDWB-A1 is a high-performance wideband beltpack transmitter designed for professional wireless audio applications in the A1 frequency band (470–537 MHz). Engineered for broadcast, film, and live production, it features a compact, rugged aluminum housing and offers advanced digital hybrid wireless technology to ensure pristine audio quality with low noise and minimal latency. The unit accommodates either one or two AA batteries, allowing users to choose between reduced size or extended run time. Its versatile design includes intuitive controls, an easy-to-read OLED display, and IR sync for seamless pairing with compatible receivers. The SMDWB-A1 is built to meet the rigorous demands of the industry with unmatched reliability and clarity.
The Key Features of the Lectrosonics SMDWB-A1:
- 75 MHz tuning range in the A1 band (470–537 MHz)
- Dual battery compartment for one or two AA cells
- Digital Hybrid Wireless® technology for studio-grade audio
- Rugged machined aluminum housing
- OLED display with intuitive menu navigation
- Selectable output power: 25, 50, or 100 mW
- IR sync for fast and accurate receiver pairing
- Wide range input gain adjustment for various microphone types
- Audio processing preserves signal integrity across dynamic ranges
- Detachable antenna for easier integration and storage
The Detailed Specifications for the Lectrosonics SMDWB-A1:
- Frequency Range: 470.100 to 537.575 MHz (A1 band)
- RF Power Output: Selectable 25 mW, 50 mW, or 100 mW
- Audio Input: Servo Bias 2.5 mm locking connector
- Input Gain Range: Adjustable from 0 to +44 dB
- Audio Frequency Response: 35 Hz to 20 kHz (±1 dB)
- THD: <0.2% (typical)
- Signal-to-Noise Ratio: 110 dB (A-weighted)
- Power Source: One or two AA batteries (alkaline, lithium, or NiMH)
- Battery Life: Up to 6.5 hours with two AA lithium batteries
- Display: OLED with auto-orientation
- Housing: Machined aluminum with protective finish
- Dimensions: 2.43 x 2.38 x 0.75 inches (without antenna)
- Weight: 3.7 oz (105 g) with batteries
