Lectrosonics - SMV Super Miniature Wireless Microphone Transmitter (Block 21: 537 to 563 MHz) (SMV-21)
Original price
$2,532.00
-
Original price
$2,532.00
Original price
$2,532.00
$2,532.00
-
$2,532.00
Current price
$2,532.00
| /
The Lectrosonics SMV Super Miniature Wireless Microphone Transmitter (Block 21: 537 to 563 MHz) is engineered for professional audio applications that demand high-quality transmission in an ultra-compact form factor. Designed for film, television, broadcast, and live performance, the SMV delivers outstanding audio performance with selectable power settings, rugged construction, and reliable digital hybrid wireless technology. Despite its small size, the SMV offers robust RF performance, user-configurable settings, and compatibility with a wide range of lavalier microphones. It’s a go-to solution when space, weight, and audio fidelity are critical.
The Key Features of the Lectrosonics SMV Super Miniature Wireless Microphone Transmitter (Block 21: 537 to 563 MHz):
- Digital Hybrid Wireless® technology for superior audio fidelity
- Operating frequency: Block 21 (537 to 563 MHz)
- Selectable RF output power: 50, 100, or 250 mW
- Ultra-compact and lightweight design for easy concealment
- Wide input gain range with DSP-controlled limiter
- Compatibility with a wide variety of lavalier microphones
- Machined aluminum housing with water-resistant construction
- OLED display for easy menu navigation and setup
- IR sync for fast and easy setup with compatible receivers
- Runs on a single AA battery (alkaline, lithium, or rechargeable)
The Detailed Specifications for the Lectrosonics SMV Super Miniature Wireless Microphone Transmitter (Block 21: 537 to 563 MHz):
- Frequency Range: 537 to 563 MHz (Block 21)
- Modulation Type: Digital Hybrid
- RF Power Output: Selectable 50, 100, or 250 mW
- Input Impedance: 2.7k Ohms, compatible with lavaliers
- Mic Input Connector: TA5M
- Input Level Range: -25 dBu to +5 dBu
- Battery Type: 1 x AA battery (alkaline, lithium, or NiMH)
- Battery Life: Up to 5.5 hours (with lithium at 50 mW)
- Display: OLED with intuitive navigation
- Dimensions: 2.3 x 2.2 x 0.64 in. (58 x 56 x 16 mm)
- Weight: 2.5 oz (71 g) with lithium battery
- Housing: Machined aluminum with waterproof sealing
