Magewell Pro Convert SDI 4K Plus (64030) – 4K SDI to NDI Encoder
Original price
$960.00
-
Original price
$960.00
Original price
$960.00
$960.00
-
$960.00
Current price
$960.00
| /
The Magewell Pro Convert SDI 4K Plus (Model 64030) is a high-performance NDI encoder designed to convert 6G-SDI signals up to 4K at 30fps into NDI streams for IP-based video production workflows. It is perfect for professional broadcasting, live event streaming, and AV-over-IP systems, offering exceptional image quality, low latency, and reliable performance. Compact, fanless, and easy to configure via a web interface, this converter is an ideal tool for integrating traditional SDI equipment into NDI infrastructures.
The Key Features of the Magewell Pro Convert SDI 4K Plus (Model 64030):
- Converts 6G-SDI video input up to 4K30 to full-bandwidth NDI stream
- Supports embedded audio and external analog audio input
- Low-latency encoding with hardware-based video processing
- Auto-detection of input format and signal resolution
- Fanless, compact metal housing for silent operation
- Power over Ethernet (PoE) support for streamlined installation
- Integrated web-based user interface for remote control and configuration
- Tally lights, PTZ control, and NDI discovery server support
- Flexible mounting options for studio or field use
The Detailed Specifications for the Magewell Pro Convert SDI 4K Plus (Model 64030):
- Video Input: 6G-SDI (up to 4096x2160p30)
- Supported Resolutions: 4096x2160p, 3840x2160p, 1080p, 720p, and more
- Audio Input: SDI embedded, 3.5mm analog line-in
- Output Protocol: Full NDI
- Network: Gigabit Ethernet with PoE (IEEE 802.3af)
- Control Interface: Web GUI, USB keyboard/mouse, On-Device buttons
- Power: PoE or USB power supply (5V/2A)
- Dimensions: 117.5mm x 66.7mm x 23.3mm (4.63" x 2.63" x 0.92")
- Weight: Approximately 190g (6.7oz)
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Mounting: Threaded holes for bracket or tripod mounting
