Magewell Director Mini Compact Live Streaming Encoder, Switcher, Monitor & Recorder
Original price
$1,299.00
-
Original price
$1,299.00
Original price
$1,299.00
$1,299.00
-
$1,299.00
Current price
$1,299.00
| /
The Magewell Director Mini (551100000) is a compact, all-in-one touchscreen production and streaming device designed for live video content creators. Combining robust switching capabilities, high-quality encoding, multi-platform streaming, and direct recording into a single portable unit, the Director Mini simplifies multi-camera productions for events, education, worship, corporate broadcasts, and mobile productions. With support for up to 4 video sources and intuitive controls, it eliminates the need for external PCs or complex wiring setups, delivering broadcast-quality output from virtually anywhere.
The Key Features of the Magewell Director Mini (551100000):
- All-in-one touchscreen device for video switching, streaming, and recording
- Supports up to four video sources simultaneously
- Two HDMI and two USB AV inputs, plus NDI|HX and streaming inputs
- 10.1-inch responsive touchscreen interface for intuitive control
- Built-in encoder for simultaneous live streaming and recording
- On-device graphics overlays, scene transitions, and audio mixing
- Compatible with RTMP, SRT, and HLS streaming protocols
- Dual USB-C ports and SD card slot for storage and expansion
- Compact, fanless design ideal for portable or desktop use
- Battery-powered operation for field use
The Detailed Specifications for the Magewell Director Mini (551100000):
- Model Number: 551100000
- Display: 10.1-inch capacitive touchscreen, 1920x1200 resolution
- Video Inputs: 2x HDMI, 2x USB AV, NDI|HX, and IP stream input
- Video Output: 1x HDMI (program output)
- Audio: Embedded HDMI, analog 3.5mm input/output, USB audio
- Recording: MP4 format, internal storage, SD card, or USB drive
- Streaming Protocols: RTMP, SRT, HLS
- Encoding: H.264 encoding up to 1080p60
- Networking: Ethernet, Wi-Fi (2.4G/5G), hotspot mode
- Power Supply: USB-C PD (power delivery), internal battery included
- Dimensions: 275mm x 148mm x 22mm
- Weight: Approx. 1.1 kg (2.4 lbs)
- Operating System: Embedded Linux
- Mounting: VESA-compatible and desktop stand ready
