Magewell Pro Convert AES67 Multi-format Bi-directional IP Audio Converter (64240)
Original price
$379.00
-
Original price
$379.00
Original price
$379.00
$379.00
-
$379.00
Current price
$379.00
| /
The Magewell Pro Convert AES67 Multi-format Bi-directional IP Audio Converter (64240) is a professional-grade audio interface designed to seamlessly bridge traditional audio sources with IP-based audio networks. Supporting AES67 and ST 2110 standards, this compact yet powerful device offers analog, AES3 digital, and USB audio inputs and outputs, making it highly versatile for broadcast, live production, and AV system integration. Its bidirectional design allows simultaneous transmission and reception of audio streams, and the intuitive web-based interface ensures easy configuration and monitoring.
The Key Features of the Magewell Pro Convert AES67 Multi-format Bi-directional IP Audio Converter (64240):
- Bi-directional IP audio conversion supporting AES67 and ST 2110-30/31 standards
- Flexible I/O options including analog, AES3 digital, and USB audio interfaces
- Low-latency audio transport with precise synchronization using PTP (IEEE 1588)
- Built-in web interface for configuration, monitoring, and firmware updates
- Supports up to 8 input and 8 output audio channels simultaneously
- Compact and robust metal enclosure for easy rack or field deployment
- PoE (Power over Ethernet) support or USB-C power input for flexible power options
The Detailed Specifications for the Magewell Pro Convert AES67 Multi-format Bi-directional IP Audio Converter (64240):
- Model: Magewell Pro Convert AES67 (64240)
- IP Audio Protocols: AES67, ST 2110-30/31
- Network Interface: 1x Gigabit Ethernet (RJ45)
- PTP Support: IEEE 1588-2008 (PTPv2)
- Analog Audio I/O: 1x stereo line in, 1x stereo line out (3.5mm TRS)
- Digital Audio I/O: 1x AES3 input, 1x AES3 output (XLR connectors)
- USB Audio: USB-C port supporting stereo audio I/O (USB Audio Class 1.0/2.0)
- Audio Channels: Up to 8 input and 8 output channels
- Latency: As low as 1 ms (network dependent)
- Configuration Interface: Web-based GUI
- Power: PoE (802.3af) or USB-C 5V power input
- Dimensions: 98.9mm x 98.9mm x 24.8mm
- Weight: Approx. 200g
- Operating Temperature: 0°C to 50°C (32°F to 122°F)
- Mounting Options: Optional rack and DIN rail mounting accessories available
