Magewell Ultra Encode HDMI Plus Universal 4K Encoder
Original price
$569.00
-
Original price
$569.00
Original price
$569.00
$569.00
-
$569.00
Current price
$569.00
| /
The Magewell Ultra Encode HDMI Plus (531500000) is a high-performance 1-channel HDMI recording and streaming device engineered for professional-grade video workflows. Designed with flexibility in mind, it supports up to 1080p60 video encoding using H.264 or H.265 compression, with simultaneous streaming to multiple platforms and protocols including RTMP, SRT, HLS, and more. Its compact, durable build makes it perfect for a wide range of applications including live event production, lecture capture, corporate communications, and remote contribution. With its advanced configuration options, intuitive interface, and seamless integration capabilities, the Ultra Encode HDMI Plus is a powerful, plug-and-play solution for content creators and AV professionals alike.
The Key Features of the Magewell Ultra Encode HDMI Plus (531500000):
- Supports HDMI input up to 4096x2160 at 60fps with 4:2:0 color sampling
- Encodes video in H.264 or H.265 with up to 1080p60 resolution
- Simultaneous live streaming and recording capabilities
- Multiple streaming protocols supported: RTMP, RTMPS, SRT, HLS, TS over UDP/RTP, and more
- Compatible with streaming platforms like YouTube, Facebook Live, and Twitch
- Gigabit Ethernet for stable and high-speed network connectivity
- Audio embedding from HDMI or analog input
- Compact, fanless design for silent operation
- Easy-to-use web interface for configuration and monitoring
- Supports ONVIF and NDI|HX2 protocols for IP-based workflows
The Detailed Specifications for the Magewell Ultra Encode HDMI Plus (531500000):
- Model Number: 531500000
- Input Interface: 1x HDMI Type-A (up to 4K60 input supported)
- Encoding Formats: H.264 (AVC), H.265 (HEVC)
- Max Encoding Resolution: 1080p60
- Audio Input: HDMI embedded or 3.5mm analog
- Network: 1x RJ45 Gigabit Ethernet
- Streaming Protocols: RTMP, RTMPS, SRT, HLS, RTP, TS over UDP, RTSP, NDI|HX2
- Recording Format: MP4 to USB storage
- USB Ports: 1x USB 3.0 Type-A (for storage), 1x USB Type-C (power and configuration)
- Power Input: 5V via USB-C, or optional power adapter
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Dimensions: 117.5mm x 66.7mm x 23.4mm (4.63in x 2.63in x 0.92in)
- Weight: Approximately 196g (6.9oz)
- Mounting: Integrated 1/4"-20 thread for tripod or rig mounting
- Management: Web GUI, HTTP APIs, and Magewell Cloud platform
