Magewell Ultra Encode SDI Plus Universal 4K Encoder
Original price
$569.00
-
Original price
$569.00
Original price
$569.00
$569.00
-
$569.00
Current price
$569.00
| /
The Magewell Ultra Encode SDI Plus (531600000) is a compact, high-performance device engineered for professional video streaming and recording applications. Featuring 3G SDI input, this encoder supports up to 1080p60 video and provides simultaneous encoding in H.264 and H.265 formats. Ideal for live production, AV integration, remote learning, and more, the Ultra Encode SDI Plus ensures seamless RTMP, SRT, HLS, and other IP-based streaming workflows with minimal latency. With flexible protocol support, intuitive controls, and broad compatibility, it's a reliable solution for content creators, broadcasters, and system integrators seeking exceptional video quality in a versatile form factor.
The Key Features of the Magewell Ultra Encode SDI Plus (531600000):
- Supports up to 1080p60 3G SDI video input and loop-through
- Simultaneous streaming and recording with H.264/H.265 encoding
- Flexible protocol support including RTMP, SRT, HLS, RTSP, and more
- Dual-stream encoding for multiple output configurations
- On-device controls and web-based UI for easy configuration
- Compact, fanless design for quiet, reliable operation
- USB and SD card recording options with adaptive bitrate support
- Ideal for live production, corporate events, education, and houses of worship
The Detailed Specifications for the Magewell Ultra Encode SDI Plus (531600000):
- Video Input: 1x 3G-SDI (up to 1080p60)
- Loop-Through: 1x 3G-SDI output for signal passthrough
- Encoding Formats: H.264/AVC and H.265/HEVC
- Streaming Protocols: RTMP, RTMPS, SRT, HLS, RTSP, TS over UDP/RTP, NDI|HX2
- Max Bitrate: Up to 32Mbps per stream
- Recording Formats: MP4, MOV (to USB or SD card)
- Audio Input: Embedded SDI or analog via 3.5mm jack
- Audio Encoding: AAC-LC
- Network Interface: 1x Gigabit Ethernet
- Control Interface: Web UI, HTTP APIs, on-device buttons
- Power Supply: 5V/2A via USB-C (power adapter included)
- Dimensions: 100.3mm x 60.6mm x 24.7mm (3.95 x 2.39 x 0.97 inches)
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Weight: Approx. 170g (6 oz)
