Panasonic AK-HCU250PSJ Camera Control Unit with LEMO Connector
Original price
$14,753.00
-
Original price
$14,753.00
Original price
$14,753.00
$14,753.00
-
$14,753.00
Current price
$14,753.00
| /
The Panasonic AK-HCU250PSJ is a high-performance Camera Control Unit (CCU) designed to work seamlessly with Panasonic's studio camera systems. Optimized for both 4K and HD production environments, it offers flexible connectivity and enhanced signal transmission over long distances. The compact, rack-mountable design is well-suited for studio, remote, or outside broadcast operations. With support for 12G-SDI, dual transmission lines, and IP streaming output, the AK-HCU250PSJ delivers reliable and high-quality video output, making it a central component of any professional broadcast system.
The Key Features of the Panasonic AK-HCU250PSJ:
- Supports 4K/HD transmission over SMPTE hybrid fiber
- 12G-SDI output for single-cable 4K signal transmission
- IP streaming output for flexible integration
- Compact 2U rack-mountable design
- Built-in audio and intercom support
- Compatible with AK-HC5000 and AK-UC4000 series cameras
- Multiple return video, tally, and trunk line support
- Integrated power supply and camera control functions
The Detailed Specifications for the Panasonic AK-HCU250PSJ:
- Video Output: 12G-SDI × 2, 3G/HD-SDI × 4
- Video Input: 3G/HD-SDI Return Inputs × 4
- IP Streaming: H.264 video streaming output supported
- Control Interface: LAN, GPI, and serial control ports
- Audio: Embedded audio via SDI and intercom support
- Power Supply: 100–240V AC, 50/60Hz
- Dimensions: 2U height, standard 19-inch rack mount
- Weight: Approx. 4.2 kg (9.26 lbs)
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Camera Compatibility: AK-UC4000, AK-HC5000 series
