Q-SYS AD-S802T-W 8-inch ceiling speaker with dual inputs and built-in amplifier, designed for clear audio in commercial spaces.

Q-SYS AD-S802T-W 8-Inch Dual-Input Ceiling Speaker

by Q-SYS
Availability:
In stock 3-5 days
$992.54 - $992.54
$992.54
$992.54 - $992.54
$992.54

SKU: AD-S802T-W

The Q-SYS AD-S802T-W is an advanced ceiling speaker designed for high-performance audio in commercial environments. Featuring an 8-inch driver and integrated amplifier, it combines power and clarity to deliver superior sound quality in spaces such as conference rooms, retail stores, and auditoriums. This model supports dual-input functionality, offering flexible connectivity for both analog and digital sources, while its sleek, low-profile design blends seamlessly into any interior.

The AD-S802T-W is optimized for the Q-SYS Ecosystem, providing easy integration with other Q-SYS audio, video, and control components. It is engineered to offer consistent, reliable performance and user-friendly operation, making it an ideal choice for businesses looking to upgrade or install a professional audio system.

The Key Features of the Q-SYS AD-S802T-W:

  • 8-Inch Full-Range Speaker: Delivers clear, rich audio with excellent coverage in commercial environments.
  • Built-In Amplifier: No external amplification required, reducing installation complexity and cost.
  • Dual-Input Support: Offers flexible connectivity for both analog and digital audio sources.
  • Q-SYS Ecosystem Integration: Seamlessly integrates with other Q-SYS devices for scalable, flexible audio solutions.
  • Commercial-Grade Durability: Designed for reliable, long-term use in a variety of commercial settings.
  • Sleek, Low-Profile Design: Subtle aesthetics that blend easily into ceilings without drawing attention.
  • Easy Installation: Quick and simple setup with minimal wiring requirements.
  • EN54-24 Compliant: Meets safety standards for use in commercial audio applications.

The Detailed Specifications for the Q-SYS AD-S802T-W:

  • Speaker Type: 8-Inch Full-Range Ceiling Speaker
  • Frequency Response: 55 Hz – 20 kHz
  • Impedance: 8 ohms
  • Power Handling: 40W RMS, 80W Peak
  • Amplifier: Integrated Class D Amplifier
  • Input Type: Dual Inputs (Analog & Digital)
  • Input Connectivity: Phoenix-style connectors (for analog) and RJ-45 (for digital)
  • Enclosure Material: High-impact ABS plastic
  • Mounting Type: Ceiling Flush Mount
  • Dimensions: 11.5" (diameter) x 4.2" (depth)
  • Weight: 6.5 lbs (2.95 kg)
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Certifications: EN54-24, UL1480, UL2043, CE, RoHS Compliant
  • Color: White (paintable)
  • Warranty: 5 years
