Q-SYS NS10-125+ 10-Port PoE+ Network Switch

Q-SYS NS10-125+ 10-Port PoE+ Network Switch

by Q-SYS
Availability:
In stock 3-5 days
$2,052.24 - $2,052.24
$2,052.24
$2,052.24 - $2,052.24
$2,052.24

SKU: NS10-125+

The Q-SYS NS10-125+ is a 10-port network switch engineered to meet the rigorous performance demands of Q-SYS audio, video, and control (AV&C) systems. Manufactured by NETGEAR and pre-configured by Q-SYS, this enterprise-grade switch offers a plug-and-play solution, streamlining deployment and reducing support requirements for integrators and IT professionals. With advanced Quality of Service (QoS) and IGMP configurations, the NS10-125+ seamlessly supports Q-LAN, AES67, and Dante audio streams within the same VLAN, ensuring flexible and reliable network scenarios.

The Key Features of the Q-SYS NS10-125+:

  • Pre-Configured for Q-SYS: Optimized settings tailored for Q-SYS AV&C systems, facilitating quick and hassle-free deployment.
  • Power over Ethernet Plus (PoE+): Eight of the ten Gigabit Ethernet ports support IEEE 802.3af/at PoE+, delivering up to 30W per port with a total power budget of 125W, providing combined power, data, and control for Q-SYS devices.
  • Flexible Network Support: Simultaneously handles Q-LAN, AES67, and Dante audio streams within the same VLAN without manual QoS adjustments, ensuring seamless integration of various audio protocols.
  • Intelligent Traffic Management: Features integrated IGMP+ for automatic multicast data management across multiple switches and an optional built-in DHCP server for automated IP connectivity in standalone AV systems.
  • Future-Ready Design: Serves as a benchmark for future Q-SYS audio and video peripherals, ensuring long-term compatibility and scalability within evolving AV infrastructures.

The Detailed Specifications for the Q-SYS NS10-125+:

Network Ports: 10 RJ45 10/100/1000 Mbps ports

  • 8 ports with PoE+ support

SFP Ports: 2 Gigabit Ethernet SFP slots for fiber connectivity

PoE Standards Supported: IEEE 802.3af (PoE), IEEE 802.3at (PoE+)

Total PoE Power Budget: 125 Watts

Network Protocols Supported: Q-LAN, AES67, Dante

Management Features:

  • Integrated IGMP+ for multicast management
  • Optional built-in DHCP server

Default IP Address: 192.168.0.120 (if no DHCP address is available)

Construction: Enterprise-grade hardware manufactured by NETGEAR

Intended Use: Standalone AV networks; not supported for applications beyond supplied configurations, such as additional VLANs or other AVC protocols.
