QuickLink StudioPro-8 professional broadcast and remote contribution system

Quicklink StudioPro-8

by Quicklink
Availability:
In stock 3-5 days
$30,023.00 - $30,023.00
$30,023.00
$30,023.00 - $30,023.00
$30,023.00

SKU: StudioPro-8

Studio Pro Specifications comparison Chart

Download PDF

  • Overview
  • Features
  • Specifications

The QuickLink StudioPro-8 is an advanced, all-in-one broadcast system designed for professional remote contribution, live production, and content delivery. With support for up to 8 remote guests in high-definition, the StudioPro-8 enables ultra-low latency communication and seamless integration with your production workflow. Equipped with an intuitive web-based interface and powered by enterprise-grade hardware, the StudioPro-8 is ideal for newsrooms, production studios, and remote broadcasters demanding top-tier video quality and reliability.

The Key Features of the Quicklink StudioPro-8:

  • Supports up to 8 simultaneous remote guests in full HD
  • End-to-end encryption for secure transmission
  • Remote control and monitoring via web-based interface
  • Integrated audio/video processing and mixing
  • NDI, SDI, and IP output options for seamless integration
  • Ultra-low latency for real-time interactions
  • Broadcast-quality video encoding and decoding
  • Compatible with all major production platforms

The Detailed Specifications for the Quicklink StudioPro-8:

  • Video Inputs: 8 x full HD guest connections via web browser
  • Video Outputs: 3G-SDI, NDI, SRT, and IP outputs
  • Audio: Embedded SDI, analog XLR, AES/EBU
  • Latency: Sub-200ms end-to-end transmission
  • Encoding: H.264/HEVC broadcast-grade encoding
  • Storage: 1TB SSD internal recording capacity
  • Network: Dual 1GbE ports, VPN-ready
  • Power Supply: Dual redundant 500W PSU
  • Interface: Web-based UI with remote control and monitoring
  • Dimensions: 2U rackmount chassis
  • Operating System: Linux-based with hardened security
