Science Image Flow Edge 4CH - 4-Channel 1U Rack-mount 4K Up/Down/Cross Converter
Availability:
In stock 3-5 days
Original price
$4,600.00
-
Original price
$4,600.00
Original price
$4,600.00
$4,600.00
-
$4,600.00
Current price
$4,600.00
| /
The Science Image Flow Edge 4CH is a professional-grade 4-channel 4K up/down/cross converter housed in a sleek 1U rack-mount chassis. Engineered for high-performance video environments, this unit delivers seamless format conversions across multiple resolutions and frame rates, supporting SD, HD, and full 4K workflows. Whether deployed in broadcast control rooms, live event production, or video distribution systems, the Flow Edge 4CH ensures accurate, real-time processing with unmatched reliability and signal integrity.
The Key Specifications of the Science Image Flow Edge 4CH:
- 4 independent 12G-SDI input/output channels with 4K UHD support
- Real-time up, down, and cross conversion capabilities
- 1U rack-mount design optimized for space-saving AV integration
- High dynamic range (HDR) and wide color gamut (WCG) support
- Customizable signal processing and routing via web-based UI
- Integrated frame sync and format detection per channel
- Multi-format compatibility: SD, HD, 3G, 6G, and 12G-SDI
- Redundant power supply for mission-critical reliability
- Quiet cooling system suitable for studio and OB van environments
- Remote control and monitoring through Ethernet and serial interfaces
The Detailed Specifications for the Science Image Flow Edge 4CH:
- Video Inputs: 4 x 12G-SDI BNC connectors (auto-detecting)
- Video Outputs: 4 x 12G-SDI BNC connectors (assignable)
- Supported Resolutions: 480i, 576i, 720p, 1080i/p, 2160p
- Frame Rates: 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps
- HDR Support: HLG, PQ, and SDR-to-HDR conversion
- Color Processing: 10-bit 4:2:2 and 4:4:4, Rec. 709 & Rec. 2020
- Latency: Sub-frame processing per channel
- Control Interface: Web UI, RS-232/422, and Ethernet (RJ-45)
- Power Supply: Dual hot-swappable 100–240V AC, 50/60Hz
- Cooling: Temperature-controlled fans with low-noise operation
- Dimensions: 19" x 1.75" x 10.2" (W x H x D)
- Weight: Approx. 8.5 lbs (3.9 kg)
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
