The Science Image Vela Rack SDI is a professional-grade, all-in-one 4K video encoder, decoder, and recorder designed for high-end broadcast, production, and research environments. Built with a user-centric 7-inch touch-screen interface, this rack-mounted unit offers powerful video processing and seamless SDI input/output support. Whether you're capturing, streaming, or recording, the Vela Rack delivers flawless real-time performance, low latency, and ultra-sharp image fidelity. Compact, rugged, and feature-rich, it's the ideal solution for any mission-critical video application.
The Key Specifications of the Science Image Vela Rack SDI:
- Integrated 4K video encoding, decoding, and recording in one device
- 7-inch capacitive touch-screen for intuitive control and monitoring
- Supports 12G/6G/3G/HD-SDI input and output
- Real-time HEVC/H.265 and H.264 encoding
- Rack-mountable 1U design for space-efficient deployment
- Dual network interfaces for redundant streaming and control
- Multiple recording formats and destinations (USB, SD card, network)
- Ultra-low latency mode for real-time applications
- Customizable encoding profiles and streaming protocols (RTSP, SRT, RTMP, HLS)
- Fanless operation for silent environments
The Detailed Specifications for the Science Image Vela Rack SDI:
- Video Input: 1x 12G/6G/3G/HD-SDI (BNC), loop-through supported
- Video Output: 1x 12G/6G/3G/HD-SDI (BNC), 1x HDMI preview
- Touchscreen Display: 7-inch 800x480 capacitive TFT
- Encoding Formats: H.265 (HEVC), H.264 (AVC)
- Max Resolution: 3840 x 2160 @ 60fps
- Recording Storage: USB 3.0, SDXC card, NAS support
- Streaming Protocols: RTMP, RTSP, SRT, HLS, RTP
- Network: 2x RJ45 Gigabit Ethernet (redundancy & control)
- Audio: Embedded SDI audio + 3.5mm stereo input/output
- Power Supply: 100-240V AC, 50/60Hz, IEC C14 connector
- Form Factor: 1U 19" rackmount chassis
- Operating Temperature: 0°C to 50°C (32°F to 122°F)
- Cooling: Passive, fanless design
- Dimensions: 482.6mm x 44.5mm x 250mm (W x H x D)
- Weight: 3.2 kg (7.05 lbs)
