Teradek Ranger Micro 2500 3G-SDI/HDMI Wireless RX - V Mount (10-2542-V)
Original price
$4,190.00
-
Original price
$4,190.00
Original price
$4,190.00
$4,190.00
-
$4,190.00
Current price
$4,190.00
| /
The Teradek Ranger Micro 2500 3G SDI/HDMI Wireless RX V-Mount (10-2542-V) is engineered for high-performance, zero-delay video transmission in professional broadcast and cinema applications. Designed with a compact V Mount form factor, the Ranger Micro delivers pristine 10-bit 4:2:2 video over 3G-SDI and HDMI up to 2,500 feet line of sight. It operates in a license-free 5GHz spectrum with smart frequency management, ensuring robust, interference-free performance on set. Built to match the rigorous demands of mobile and studio environments, this receiver is ideal for high-end productions needing reliable and high-quality wireless video monitoring.
The Key Features of the Teradek Ranger Micro 2500 3G SDI/HDMI Wireless RX V-Mount (10-2542-V):
- Wireless video reception up to 2,500 ft (line of sight)
- Supports 3G-SDI and HDMI video outputs
- Zero-delay (<1 ms) transmission for real-time monitoring
- License-free 5GHz frequency operation
- Smart RF frequency hopping for optimal signal stability
- 10-bit 4:2:2 image fidelity with ultra-low latency
- Compact and lightweight design with integrated V Mount
- Compatible with Teradek Ranger and Bolt 4K ecosystems
- Built for on-set use with rugged, professional-grade construction
The Detailed Specifications for the Teradek Ranger Micro 2500 3G SDI/HDMI Wireless RX V-Mount (10-2542-V):
- Model Number: 10-2542-V
- Video Output: 1x 3G-SDI, 1x HDMI 2.0
- Wireless Range: Up to 2,500 feet (line of sight)
- Latency: <1 millisecond (zero-delay)
- Video Format Support: Up to 1080p60, 10-bit 4:2:2
- RF Band: 5GHz ISM (dual-band)
- Mount Type: Integrated V Mount battery plate
- Power Input: 2-pin locking connector (7–17V DC)
- Dimensions: Approx. 4.5 x 3.1 x 1.0 inches (without antennas)
- Weight: Approx. 9 oz (without battery)
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Compatibility: Works with Ranger and Bolt 4K series transmitters
