Teradek Ranger MK II 2500 12G-SDI/HDMI Wireless RX V Mount (10-2592-V)
Original price
$5,990.00
-
Original price
$5,990.00
Original price
$5,990.00
$5,990.00
-
$5,990.00
Current price
$5,990.00
| /
The Teradek Ranger MK II 2500 12G SDI/HDMI Wireless RX V Mount (10-2592-V) is a cutting-edge wireless video receiver built for demanding broadcast and cinematic environments. Designed to deliver uncompromising video quality and ultra-low latency, the Ranger MK II 2500 supports up to 12G-SDI and HDMI video outputs, accommodating resolutions up to 4Kp60. With an impressive line-of-sight transmission range of up to 5,000 feet, this rugged receiver integrates seamlessly into professional workflows. The included V Mount battery plate enhances mobility, making it ideal for location shoots and dynamic production scenarios.
The Key Features of the Teradek Ranger MK II 2500 12G SDI/HDMI Wireless RX V Mount (10-2592-V):
- Supports 12G-SDI and HDMI video outputs for high-resolution workflows
- Wireless range up to 5,000 ft (1,524 m) line-of-sight
- Zero-delay (<1 ms) transmission for real-time monitoring
- Compatible with all Teradek Ranger MK II transmitters
- High-performance 5GHz and 6GHz (UNII-5) dual-band operation
- Rugged, compact housing with integrated V Mount battery plate
- Encrypted transmission with AES-256 and RSA 1024 key exchange
- Intuitive front-facing OLED display for easy configuration
- Low power consumption for efficient field use
The Detailed Specifications for the Teradek Ranger MK II 2500 12G SDI/HDMI Wireless RX V Mount (10-2592-V):
- Model Number: 10-2592-V
- Video Outputs: 1x 12G-SDI, 1x HDMI 2.0
- Resolution Support: Up to 4Kp60
- Latency: <1 ms (zero delay)
- Wireless Range: Up to 5,000 ft (1,524 m) line-of-sight
- Wireless Frequency Bands: 5GHz and 6GHz (UNII-5)
- Encryption: AES-256 with RSA 1024 key exchange
- Mounting Type: V Mount Battery Plate
- OLED Display: Yes, front-facing for status and settings
- Power Input: 2-pin LEMO (6–34V DC)
- Construction: Durable aluminum chassis
- Dimensions: Approx. 6.1 x 3.8 x 1.1 in (155 x 97 x 28 mm)
- Weight: Approx. 1.1 lbs (0.5 kg)
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
