Teradek Ranger MK II 2500 12G-SDI/HDMI Wireless TX/RX Deluxe Kit Gold Mount (10-2590-G)
Original price
$13,490.00
-
Original price
$13,490.00
Original price
$13,490.00
$13,490.00
-
$13,490.00
Current price
$13,490.00
| /
The Teradek Ranger MK II 2500 12G-SDI/HDMI Wireless TX/RX Deluxe Kit Gold Mount (10-2590-G) is a zero-delay, high-performance wireless video transmission solution designed for professional filmmakers and broadcast productions. Engineered for the most demanding environments, the Ranger MK II delivers uncompressed 4K HDR video up to 2,500 feet line-of-sight using a resilient 5GHz and 6GHz (U-NII 5) frequency band. This deluxe kit includes both a transmitter and receiver, each equipped with Gold Mount battery plates for seamless on-set power integration. With 12G-SDI and HDMI I/O, secure AES-256 encryption, and spectrum analysis tools, the Ranger MK II empowers crews to operate with flexibility, clarity, and confidence—whether on set, on location, or in the field.
The Key Features of the Teradek Ranger MK II 2500 12G-SDI/HDMI Wireless TX/RX Deluxe Kit Gold Mount (10-2590-G):
- Zero-delay (<1ms) wireless video transmission up to 2,500 feet line-of-sight
- Supports uncompressed 10-bit 4K HDR video over 12G-SDI and HDMI
- Operates on 5GHz and 6GHz frequency bands, including U-NII 5 (6GHz)
- Encrypted transmission with AES-256 and RSA 1024 key exchange
- Gold Mount power plates on both transmitter and receiver
- High-performance RF with smart frequency hopping and DFS support
- Built-in spectrum analyzer and signal strength monitoring
- Compatible with Teradek Bolt 4K series receivers and Bolt Manager software
- Rugged aluminum chassis for durability in production environments
- Multiple mounting options with 1/4"-20 and ARRI accessory mounts
The Detailed Specifications for the Teradek Ranger MK II 2500 12G-SDI/HDMI Wireless TX/RX Deluxe Kit Gold Mount (10-2590-G):
- Transmission Range: Up to 2,500 feet (line-of-sight)
- Video Inputs: 1x 12G-SDI, 1x HDMI 2.0 (Transmitter)
- Video Outputs: 2x 12G-SDI, 1x HDMI 2.0 (Receiver)
- Video Format Support: Up to 4Kp60 (4:2:2, 10-bit)
- Latency: Less than 1 millisecond
- Frequency Bands: 5GHz, 6GHz (U-NII 5, DFS compliant)
- Encryption: AES-256 with RSA 1024 key exchange
- Mount Type: Gold Mount on both TX and RX units
- Power Input: 2-pin LEMO, 6–28V DC
- Construction: Anodized aluminum chassis
- Compatibility: Bolt 4K series, Ranger RX/Tracker RX
- Operating Temperature: -10°C to 50°C (14°F to 122°F)
- Weight: TX – Approx. 1.1 lb / RX – Approx. 1.3 lb
