Teradek Ranger MK II 2500 12G-SDI/HDMI Wireless TX/RX Deluxe Kit V Mount (10-2590-V)
Original price
$13,490.00
-
Original price
$13,490.00
Original price
$13,490.00
$13,490.00
-
$13,490.00
Current price
$13,490.00
| /
The Teradek Ranger MK II 2500 12G-SDI/HDMI Wireless TX/RX Deluxe Kit V Mount (10-2590-V) is a state-of-the-art wireless video solution engineered for demanding broadcast and cinema productions. Delivering uncompressed 10-bit 4K HDR video at up to 60fps with zero delay, the Ranger MK II features a robust 2.5-mile transmission range and supports both 12G-SDI and HDMI connectivity. Designed with interference-free operation in mind, it uses patented RF technology and operates in the 5GHz and licensed 4.9GHz bands for superior reliability. The ruggedized V Mount design ensures field-readiness, while AES-256 encryption guarantees secure content delivery. Ideal for professional DITs, live production crews, and cinematic environments.
The Key Features of the Teradek Ranger MK II 2500 12G-SDI/HDMI Wireless TX/RX Deluxe Kit V Mount (10-2590-V):
- Supports uncompressed 10-bit 4K60 HDR video transmission
- 12G-SDI and HDMI 2.0 inputs and outputs
- Zero-delay wireless video with sub-frame latency
- Up to 2.5 miles (4 km) line-of-sight range
- Operates on both 5GHz and licensed 4.9GHz frequency bands
- Patented RF technology for interference-free operation
- Military-grade AES-256 encryption for secure transmission
- Smart V Mount design for seamless on-camera integration
- Integrated spectrum analyzer and signal strength tools
- Durable aluminum chassis built for field reliability
The Detailed Specifications for the Teradek Ranger MK II 2500 12G-SDI/HDMI Wireless TX/RX Deluxe Kit V Mount (10-2590-V):
- Model Number: 10-2590-V
- Video Input/Output: 12G-SDI, HDMI 2.0 (TX and RX)
- Resolution Support: Up to DCI 4K (4096 x 2160) at 60fps
- Latency: <1 ms (zero-delay)
- Range: Up to 2.5 miles (4 km) line-of-sight
- Frequency Bands: 4.9GHz (licensed), 5.1–5.9GHz (unlicensed)
- Encryption: AES-256 with RSA 1024 key exchange
- Mount Type: V Mount (TX and RX)
- Construction: Milled aluminum chassis, fanless design
- Power Input: 6–28V DC, 2-pin LEMO
- Software: Teradek web UI, Smart 7 monitor compatibility
- Operating Temperature: -20°C to 50°C (-4°F to 122°F)
- Dimensions (TX): 4.7 x 3.1 x 1.1 in (119 x 79 x 27 mm)
- Dimensions (RX): 5.5 x 4.2 x 1.3 in (140 x 107 x 33 mm)
- Weight: TX: 1.2 lbs (0.54 kg), RX: 1.5 lbs (0.68 kg)
