Teradek Ranger MK II 5000 12G-SDI/HDMI Wireless TX 26V Gold Mount (10-2596-G26)
Original price
$9,990.00
-
Original price
$9,990.00
Original price
$9,990.00
$9,990.00
-
$9,990.00
Current price
$9,990.00
| /
The Teradek Ranger MK II 5000 12G-SDI/HDMI Wireless TX 26V Gold Mount (10-2596-G26) is a cutting-edge, zero-delay wireless video transmission system engineered for the most demanding film and broadcast workflows. With an ultra-long range of up to 5,000 feet line-of-sight, the Ranger MK II delivers uncompressed 4K and HDR video with rock-solid reliability and sub-frame latency. This Gold Mount version ensures seamless power integration with professional cinema and ENG cameras. Featuring both 12G-SDI and HDMI inputs, built-in AES-256 encryption, and seamless interoperability with Ranger MK II receivers, this transmitter is built for large-scale productions, multi-cam environments, and aerial or studio shoots that demand uncompromised video integrity and wireless flexibility.
The Key Features of the Teradek Ranger MK II 5000 12G-SDI/HDMI Wireless TX 26V Gold Mount (10-2596-G26):
- Zero-delay 12G-SDI/HDMI wireless video transmission
- Up to 5,000 ft line-of-sight range with ultra-low latency
- Supports 4Kp60 and HDR video formats
- Secure AES-256 and RSA 1024 video encryption
- Integrated Gold Mount plate for direct camera power
- Adaptive RF technology for reliable performance in crowded environments
- Uncompressed, real-time video for professional film and broadcast use
- Compatible with all Teradek Ranger MK II receivers
The Detailed Specifications for the Teradek Ranger MK II 5000 12G-SDI/HDMI Wireless TX 26V Gold Mount (10-2596-G26):
- Model Number: 10-2596-G26
- Video Input: 1x 12G-SDI, 1x HDMI 2.0
- Max Resolution: 4Kp60 (HDMI), 1080p60 (SDI backward compatibility)
- Wireless Range: Up to 5,000 ft (1.5 km) line-of-sight
- Latency: Sub-frame (zero-delay)
- Encryption: AES-256 with RSA 1024 key exchange
- Mount Type: Gold Mount with pass-through power
- Frequency Band: 5GHz UNII-1/2/2e/3, DFS compliant
- RF Modulation: OFDM
- Dimensions: 6.4 x 3.0 x 1.1 inches (without antennas)
- Weight: Approx. 1.6 lbs (730g)
- Power Input: 6-28V DC via 2-pin LEMO or Gold Mount plate
- Operating Temperature: -10°C to 50°C (14°F to 122°F)
- Compatibility: Works with all Teradek Ranger MK II receivers
