Teradek Ranger MK II 5000 12G-SDI/HDMI Wireless TX/RX Deluxe Kit Gold Mount (10-2595-G)
Original price
$16,490.00
-
Original price
$16,490.00
Original price
$16,490.00
$16,490.00
-
$16,490.00
Current price
$16,490.00
| /
The Teradek Ranger MK II 5000 12G SDI/HDMI Wireless TX/RX Deluxe Kit Gold Mount (10-2595-G) delivers professional-grade, zero-delay wireless video transmission with a robust 5000 ft line-of-sight range. Designed for high-performance production environments, this advanced TX/RX system supports uncompressed 4K and HDR video via 12G-SDI and HDMI connections. The integrated Gold Mount battery plates offer on-the-go power flexibility, while the AES-256 encryption ensures secure video transmission. Whether for cinema, broadcast, or multi-cam events, the Ranger MK II provides unmatched signal integrity, rugged durability, and exceptional image quality.
The Key Features of the Teradek Ranger MK II 5000 12G SDI/HDMI Wireless TX/RX Deluxe Kit Gold Mount (10-2595-G):
- Uncompressed wireless video up to 4Kp60 with zero delay
- 12G-SDI and HDMI 2.0 input/output support
- Up to 5000 feet of range (line-of-sight)
- Secure AES-256 and RSA 1024 encryption
- Gold Mount battery plates on both TX and RX
- Broadcast-grade signal reliability with proprietary RF technology
- Multicast support to multiple receivers simultaneously
- Optimized for HDR, 10-bit, and 4:2:2 workflows
- Robust aluminum chassis for demanding environments
- Compatible with Bolt Manager App for configuration and monitoring
The Detailed Specifications for the Teradek Ranger MK II 5000 12G SDI/HDMI Wireless TX/RX Deluxe Kit Gold Mount (10-2595-G):
- Video Input (Transmitter): 1x 12G-SDI, 1x HDMI 2.0
- Video Output (Receiver): 2x 12G-SDI, 1x HDMI 2.0
- Supported Resolutions: Up to 4Kp60
- Transmission Distance: Up to 5000 ft (1524 m) line-of-sight
- Latency: <1 ms (zero-delay)
- Encryption: AES-256 with RSA 1024 key exchange
- Frequency Bands: 5GHz UNII-1, UNII-2, UNII-2e, UNII-3
- Power Input: 2-pin LEMO (10-34V DC), Gold Mount plates
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Construction: Milled aluminum chassis with passive cooling
- Mounting: 1/4"-20 and M3 mounting points
- Dimensions (TX/RX): Approx. 5.6 x 3.5 x 1.3 in / 6.1 x 4.5 x 1.5 in
- Weight (TX/RX): Approx. 1.1 lb / 1.5 lb
