Teradek Ranger MK II 750 12G-SDI/HDMI Wireless TX/RX Set Gold Mount (10-2580-G)
Original price
$8,490.00
-
Original price
$8,490.00
Original price
$8,490.00
$8,490.00
-
$8,490.00
Current price
$8,490.00
| /
The Teradek Ranger MK II 750 12G-SDI/HDMI Wireless TX/RX Set Gold Mount (10-2580-G) is a high-performance zero-delay video transmission system designed for demanding on-set environments. Supporting up to 4Kp60 via 12G-SDI and HDMI, the Ranger MK II provides a robust, license-free solution for delivering high-quality video over a 750 ft line-of-sight range. With ultra-low latency (<1ms), military-grade encryption, and support for HDR workflows, this kit ensures reliable, real-time video monitoring for broadcast, cinema, and live production. The Gold Mount battery plates allow seamless integration with professional power systems, offering flexibility and extended runtime.
The Key Features of the Teradek Ranger MK II 750 12G-SDI/HDMI Wireless TX/RX Set Gold Mount (10-2580-G):
- Zero-delay (<1ms) 4Kp60 wireless video transmission
- 12G-SDI and HDMI inputs/outputs for flexible connectivity
- 750 ft line-of-sight range with AES-256 encryption
- HDR support and uncompressed 10-bit 4:2:2 image quality
- Gold Mount battery plates for integrated power options
- Real-time RF spectrum analyzer and auto frequency hopping
- Compatible with Bolt 4K ecosystem for scalable workflows
- Dual-band (5GHz/6GHz) operation with license-free frequencies
- Durable, fanless design ideal for field production
The Detailed Specifications for the Teradek Ranger MK II 750 12G-SDI/HDMI Wireless TX/RX Set Gold Mount (10-2580-G):
- Video Inputs: 1x 12G-SDI, 1x HDMI 2.0 (TX)
- Video Outputs: 2x 12G-SDI, 1x HDMI 2.0 (RX)
- Video Resolution Support: Up to 4Kp60 (10-bit 4:2:2)
- Latency: Less than 1 millisecond
- Transmission Range: Up to 750 ft (228 m) line-of-sight
- RF Bands: 5GHz and 6GHz (where permitted)
- Encryption: AES-256 with RSA 1024 key exchange
- Mounting: Gold Mount battery plates (both TX & RX)
- Power Input: 6-34V DC via 2-pin connector or battery mount
- Dimensions (TX): 4.9” x 3.1” x 1.2”
- Dimensions (RX): 6.1” x 4.4” x 1.2”
- Weight (TX): 0.8 lbs (approx.)
- Weight (RX): 1.2 lbs (approx.)
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Compatibility: Works with Bolt 4K MAX, Bolt 4K LT, and Bolt 6 series
