Vizrt Viz Connect Solo I/O 12G-SDI Converter

by Vizrt
Availability:
In stock 3-5 days
Original price $1,295.00 - Original price $1,295.00
Original price
$1,295.00
$1,295.00 - $1,295.00
Current price $1,295.00

A compact, high-performance solution designed for professional broadcast and live production environments. It provides seamless bidirectional conversion between 12G-SDI and IP-based workflows using NDI® or SMPTE 2110 standards.

(Note: Not compatible with NDI|HX streams)

SKU: VCS12G

MPN: FG-003293-R001

The Vizrt Viz Connect Solo I/O 12G-SDI Converter (VCS12G) is a compact, high-performance solution designed for professional broadcast and live production environments. It provides seamless bidirectional conversion between 12G-SDI and IP-based workflows using NDI® or SMPTE 2110 standards. With ultra-low latency, a durable build, and high-quality video fidelity, the VCS12G enhances your live video setup with powerful, plug-and-play simplicity. Perfect for remote productions, mobile units, and hybrid studios, this device integrates effortlessly into Vizrt’s ecosystem and other industry-standard production environments.

The Key Features of the Vizrt Viz Connect Solo I/O 12G-SDI Converter (VCS12G):

  • Bidirectional 12G-SDI to IP video conversion
  • Support for NDI®, NDI®|HX, and SMPTE 2110
  • Ultra-low latency streaming and video transport
  • Robust metal chassis for field or studio deployment
  • Plug-and-play design with automatic signal detection
  • Integrated tally, PTZ control, and audio embedding
  • Seamless integration with Vizrt and third-party ecosystems
  • Compact and portable form factor

The Detailed Specifications for the Vizrt Viz Connect Solo I/O 12G-SDI Converter (VCS12G):

  • Video Input: 1 x 12G-SDI BNC (75 Ohm)
  • Video Output: 1 x 12G-SDI BNC (loop or program out)
  • Network Interface: 1 x RJ-45 1GbE, NDI®/SMPTE 2110 compatible
  • Supported Resolutions: Up to 2160p60 (4K UHD)
  • Encoding Formats: NDI®, NDI®|HX, SMPTE ST 2110
  • Audio Support: 16-channel embedded SDI, NDI® audio compatible
  • Control: Web-based UI, NDI Tools, and Vizrt workflow integration
  • Power: 12V DC input, external power supply included
  • Chassis: Durable metal housing with mounting options
  • Dimensions: 140 x 100 x 30 mm (W x D x H)
  • Weight: 0.7 kg (1.5 lbs)
  • Operating Temperature: 0°C to 40°C (32°F to 104°F)
