AJA FiDO-1T-SC 3G-SDI to single-mode SC fiber optic transmitter, compact mini-converter for high-quality video signal extension.

AJA Single SC 3G Fiber

by AJA
Availability:
In stock 3-5 days
$255.00 - $255.00
$255.00
$255.00 - $255.00
$255.00

MODEL: FIBERSC-1-RX

SKU: FIBERSC-1-RX
  • Overview
  • Features
  • Specifications

The AJA FiDO-1T-SC is a compact 3G-SDI to SC fiber optic transmitter, designed for extending HD video signals over long distances using single-mode fiber. It ensures reliable, low-latency transmission, ideal for broadcast and professional video applications.

  • Converts 3G-SDI to SC fiber
  • Supports HD and SD video formats
  • Compact, rugged enclosure
  • Single-mode fiber transmission
  • SC optical connector
  • Real-time, low-latency signal conversion
  • Supports embedded SDI audio
  • Ideal for long-distance signal transport
  • Locking power connector
  • Plug-and-play operation
  • Video Input: 1x 3G-SDI BNC, SMPTE 259/292/424
  • Video Output: 1x SC optical fiber
  • Supported Formats: Up to 1080p 60 (3G-SDI)
  • Audio Support: Embedded SDI audio
  • Fiber Type: Single-mode
  • Wavelength: 1310 nm
  • Max Cable Length: Up to 10 km (single-mode fiber)
  • Power: +5-20V DC, 1.6W
  • Connector Type: SC
  • Dimensions: 5.8" x 1.0" x 0.8" (147mm x 25mm x 20mm)
  • Operating Temperature: 0°C to 40°C (32°F to 104°F)
