Q-SYS AC-C6T 6.5-inch two-way ceiling speaker with 70V/100V transformer for commercial audio applications.

Q-SYS AC-C6T

by Q-SYS
Availability:
In stock 3-5 days
$485.07 - $485.07
$485.07
$485.07 - $485.07
$485.07

SKU: AC-C6T

The Q-SYS AC-C6T is a high-performance 6.5-inch two-way ceiling speaker designed for commercial audio applications, including retail stores, restaurants, corporate offices, and hospitality venues. Engineered for seamless integration with Q-SYS networked audio solutions, this speaker delivers premium sound quality with smooth frequency response and broad dispersion. The AC-C6T features a 70V/100V transformer and a 16-ohm bypass setting, providing installation flexibility for various system configurations. With a magnetic grille and a low-profile design, it blends aesthetically into any ceiling while ensuring easy installation and maintenance.

The Key Features of the Q-SYS AC-C6T:

  • 6.5" Two-Way Design – Delivers clear, full-range audio with a coaxially mounted high-frequency transducer.
  • 70V/100V Transformer – Supports distributed audio systems with multiple tap settings.
  • 16-Ohm Bypass Mode – Allows for direct low-impedance operation.
  • Wide Coverage Pattern – Ensures consistent sound distribution with a 130° conical dispersion.
  • Magnetic Grille – Sleek, paintable grille for a seamless ceiling appearance.
  • Easy Installation – Features a blind-mount, dog-leg style installation mechanism.
  • Optimized for Q-SYS Ecosystem – Works natively with Q-SYS DSPs and amplifiers for maximum performance.

The Detailed Specifications for Q-SYS AC-C6T:

Speaker Type: Two-way, full-range ceiling speaker

Woofer: 6.5" (165mm) treated paper cone

Tweeter: 0.86" (22mm) silk dome tweeter

Frequency Response: 65 Hz – 20 kHz (-10 dB)

Nominal Coverage: 130° conical dispersion

Transformer Tap Settings:

  • 70V: 30W, 15W, 7.5W, 3.8W
  • 100V: 30W, 15W, 7.5W

Low-Impedance Mode: 16Ω bypass

Sensitivity: 89 dB SPL (1W @ 1m)

Maximum SPL: 108 dB SPL

Power Handling: 30W continuous / 60W program

Mounting Mechanism: Blind-mount dog-leg system

Grille: Magnetic, paintable

Enclosure Material: ABS plastic with steel backcan

Cutout Diameter: 8.3" (211mm)

Mounting Depth: 8.3" (210mm)

Weight: 6.6 lbs (3.0 kg)

Certifications: UL 1480, UL 2043, CE, RoHS
