Science Image Flow Edge 2CH - 2-Channel 1U Rack-mount 4K Up/Down/Cross Converter
Availability:
In stock 3-5 days
Original price
$2,690.00
-
Original price
$2,690.00
Original price
$2,690.00
$2,690.00
-
$2,690.00
Current price
$2,690.00
| /
The Science Image Flow Edge 2CH is a professional-grade 4K signal converter engineered for broadcast, production, and high-end AV workflows. Housed in a compact 1U rack-mount chassis, this device offers reliable up, down, and cross conversion between SD, HD, and Ultra HD video formats. With superior image processing, it ensures pristine video output while maintaining signal integrity across formats. Ideal for live events, studio production, or AV installations, the Flow Edge 1CH delivers performance, flexibility, and seamless integration for mission-critical applications.
The Key Features of the Science Image Flow Edge 2CH:
- Dual 4K channels for simultaneous conversion and processing
- Supports up, down, and cross conversion between 4K, UHD, HD, and SD
- 1U rack-mountable chassis for efficient space usage
- Ultra-low latency processing for live broadcast applications
- Robust input/output options including 12G-SDI, HDMI, and fiber
- Intuitive front panel controls with LCD display for real-time monitoring
- Web-based remote control and firmware updates
- Redundant power supply support for maximum reliability
The Detailed Specifications for the Science Image Flow Edge 2CH:
- Video Channels: 2 independent 4K channels
- Supported Formats: 4K (2160p60/59.94/50), UHD, 1080p/i, 720p, SD
- Conversion Modes: Up-conversion, down-conversion, cross-conversion
- Video Inputs: 12G-SDI x 2, HDMI 2.0 x 2, Optional Fiber Input
- Video Outputs: 12G-SDI x 2, HDMI 2.0 x 2, Optional Fiber Output
- Audio Support: Embedded 16-channel SDI audio pass-through
- Latency: Less than 1 frame
- Control Interface: Front panel, web UI, RS-232, and GPI
- Network: 1 x RJ-45 (Gigabit Ethernet)
- Power Supply: Dual redundant hot-swappable PSUs (100-240V AC)
- Dimensions: 1U height, 19” rack width, 12” depth
- Operating Temperature: 0°C to 45°C (32°F to 113°F)
- Weight: Approx. 6.5 kg (14.3 lbs)
