Science Image Studio Edge 4CH - 4-Channel 1U Rack-Mount Bi-Directional 4K SDI / HDMI Full NDI Converter
Availability:
In stock 3-5 days
Original price
$5,150.00
-
Original price
$5,150.00
Original price
$5,150.00
$5,150.00
-
$5,150.00
Current price
$5,150.00
| /
The Science Image Studio Edge 4CH is a professional-grade 1U rack-mount NDI converter engineered for high-end broadcast, production, and live-streaming workflows. Featuring four independent bi-directional channels, this unit supports real-time 4K UHD video signal conversion between SDI, HDMI, and Full NDI, making it a powerful and flexible solution for studios and remote production environments. With its robust build and seamless integration capabilities, the Studio Edge 4CH is ideal for modern IP-based video systems, ensuring broadcast-quality image fidelity, ultra-low latency, and unmatched reliability across all channels.
The Key Features of the Science Image Studio Edge 4CH:
- 4 independent bi-directional channels for simultaneous encode and decode
- Supports 4K UHD resolution at up to 60fps for SDI and HDMI
- Full NDI protocol support for high-quality, low-latency IP transmission
- 1U rack-mountable design for efficient studio and OB van integration
- Flexible signal routing between SDI, HDMI, and NDI inputs/outputs
- High-performance FPGA processing ensures real-time operation
- Gigabit and 10-Gigabit Ethernet compatibility for seamless network integration
- Web-based control interface for easy configuration and monitoring
- Robust metal chassis with active cooling for long-term reliability
- Ideal for live production, broadcasting, and AV installations
The Detailed Specifications for the Science Image Studio Edge 4CH:
- Video Channels: 4x Independent Bi-Directional (Encode/Decode)
- Video Resolutions Supported: Up to 3840x2160p60 (4K UHD)
- Video Interfaces: 4x 12G-SDI BNC, 4x HDMI 2.0
- NDI Format: Full NDI (Not NDI|HX)
- Network Interfaces: 2x RJ-45 (1x Gigabit, 1x 10G SFP+)
- Control Interface: Web GUI via Ethernet
- Power Supply: 100–240V AC, Integrated PSU
- Form Factor: 1U Rack-Mountable
- Cooling: Active Cooling with Intelligent Fan Control
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Dimensions: 19" x 1.75" x 10" (482mm x 44mm x 254mm)
- Weight: 3.5 kg (7.7 lbs)
