Science Image Studio Edge 6CH - 6-Channel 1U Rack-mount Bi-Directional 4K SDI / HDMI Full NDI Converter
Availability:
In stock 3-5 days
Original price
$7,200.00
-
Original price
$7,200.00
Original price
$7,200.00
$7,200.00
-
$7,200.00
Current price
$7,200.00
| /
The Science Image Studio Edge 6CH is a powerful 6-channel bi-directional 4K converter designed for demanding broadcast, production, and AV over IP environments. Housed in a compact 1U rack-mount chassis, this unit supports seamless conversion between 12G/6G/3G-SDI, HDMI 2.0, and Full NDI® (Network Device Interface), enabling versatile signal routing and distribution across IP-based systems. With six independent channels, each capable of encoding or decoding in 4K resolution, it provides unmatched flexibility for high-performance media workflows. Its robust design, intuitive interface, and exceptional image quality make it the ultimate tool for live production, post-production, and remote collaboration setups.
The Key Features of the Science Image Studio Edge 6CH:
- 6 independent 4K channels supporting bi-directional SDI/HDMI to Full NDI® conversion
- Supports 12G/6G/3G-SDI and HDMI 2.0 for high-resolution signal processing
- 1U rack-mountable design for space-efficient integration
- NDI encoding and decoding up to 4Kp60 resolution per channel
- Low-latency, broadcast-grade video over IP with NDI® 5 support
- Intuitive web-based control interface with remote management capabilities
- Independent routing and monitoring for each input/output channel
- Redundant power supply options for mission-critical reliability
- Compatible with leading production switchers, media servers, and NDI® ecosystems
The Detailed Specifications for the Science Image Studio Edge 6CH:
- Form Factor: 1U Rack Mount
- Channels: 6 independent bi-directional I/O channels
- Video Input/Output: 12G/6G/3G-SDI and HDMI 2.0
- NDI Support: Full NDI®, NDI|HX compatible (encoding & decoding)
- Max Resolution: 4Kp60 per channel
- Network Interface: Dual 10GbE RJ45 or SFP+ ports
- Control Interface: Web UI, REST API, and local touchscreen (optional)
- Audio Support: Embedded audio pass-through, up to 16 channels
- Timecode: Supports VITC, LTC, and NTP synchronization
- Power Supply: Dual redundant hot-swappable PSUs (AC 100-240V)
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Dimensions: 19” W x 1.75” H x 12” D (standard 1U)
- Weight: Approx. 8.5 lbs (3.9 kg)
